Medium Storage Unit
Assembly Instructions
Dimensions
Width - 32.5cm
Depth - 30.1cm
Height - 119.2cm
Important
- Please read these instructions fully before starting assembly
If you need help or have damaged or missing parts, call the Customer Helpline: 08456 400800
- Please keep for future reference
833/2471
Version 2 Date: 26/09/11
Advertisement
Related Manuals for Argos Medium Storage Unit 833/2471
Summary of Contents for Argos Medium Storage Unit 833/2471
- Page 1 Medium Storage Unit 833/2471 Assembly Instructions - Please keep for future reference Dimensions Width - 32.5cm Depth - 30.1cm Height - 119.2cm Important - Please read these instructions fully before starting assembly If you need help or have damaged or missing parts, call the Customer Helpline: 08456 400800 Version 2 Date: 26/09/11...
- Page 2 Safety and Care Advice Important - Please read these instructions fully before starting assembly • Check you have all the • Do not stand on the product, • We do not components and tools listed on this could cause damage. recommend the pages 2 and 3.
- Page 3 Components - Panels If you have damaged or missing components, call the Customer Helpline: 08456 400800 Please check you have all the panels listed below Pilot holes for guidance only Left side panel Back panel (117.6 x 29.9cm) (107.9 x 30cm) Pilot holes for guidance only Drawer left Drawer right...
-
Page 4: Tools Required
Components - Fittings Note: may be supplied than are required. Wooden dowel x 16 30mm Screw x 14 50mm Screw x 12 14mm Screw x 9 15mm Screw x 2 12mm Screw x 1 Door stopper x 1 Door hinge x 2 Handle x 3 Hinge plug x 1 Screw cover x 12... - Page 5 Assembly Instructions Step 1 itting hinges and handle to door Metal plate onto the Door Insert the Door hinges into the Door Handle onto the Door...
- Page 6 Assembly Instructions Step 2 Fitting dowels and door stopper Caution: Always check the assembly method is correct before applying glue. Door stopper onto the Shelf Place a small amount of Glue into the dowel holes. Insert Wooden dowels into the Shelf Place a small amount of Glue into the dowel...
- Page 7 Assembly Instructions Step 3 Fitting the bottom panel Place a small amount of Glue into the dowel holes. Insert Wooden dowels into the Bottom panel Insert Hinge plug into the Bottom panel Plastic supports onto the Front panel Finished front edge Finished front edge Front panel...
- Page 8 Assembly Instructions Step 4 Attaching runners Middle hole Position the Runners in from front edge of the Right side panel 17mm Slide top of the runners back. Runners on the Right side panel Note: The front part of the Runner should be approximately 1.7cm from the front edge of the panel.
- Page 9 Assembly Instructions Step 4 - continued Middle hole Position the Runners in from front edge of the Left side panel Slide top of the runners 17mm back. Runners on the Left side panel Note: The front part of the Runner should be approximately 1.7cm from the front edge of the panel.
- Page 10 Assembly Instructions Step 5 Fitting left side panel Place a small amount of Glue into the dowel holes. Position Bottom panel onto Left side panel using Screws Plastic supports onto the Left side panel Use Screw cover cover the Screw heads. Place a small amount of Glue into the dowel...
- Page 11 Assembly Instructions Step 6 Fitting the back panel Note: It would be useful to ask someone to help you at this stage. Place a small amount of Glue into the groove. Carefully slide the Back panel onto the unit. Step 6 Step 7 Fitting the right side panel...
- Page 12 Assembly Instructions Step 9 Drawer assembly Fix Drawer right and left side panels & to Drawer back panel using Screws Place a small amount of Glue into the grooves. Carefully slide the Drawer Screw Locking pins into the Drawer front panel Note: Insert Locking pins as far as shown.
- Page 13 Assembly Instructions Step 9 continued Insert 4 Locking nuts into the holes in the drawer sides(they will only insert one way). Use a screwdriver to turn Locking nuts clockwise to lock. Repeat with remaining drawer. Step 10 Inserting drawers Slide the assembled drawers fully onto the runners so the runners butt up against the back of the...
- Page 14 Assembly Instructions Step 11 Note: Wall plugs supplied are wall for solid wall only. Fixing to wall be used for your wall, seek It is recommended that the professional advice if in doubt strap onto the back of top panel. Top panel With help, move unit into position.
-
Page 15: A Guide To - Wall Mounting & Fixings
A Guide to - Wall Mounting & Fixings Important: When drilling into walls always Important note: check that there are no hidden wires or pipes etc. If plastic wall plugs Make sure that the screws and wall plugs being used are supplied with your are suitable for supporting your unit.
