Free stack
Debug 5V probe
Debug 12V probe
Debug 12V exp
Notes:
(1) the submenu is visible on condition that the application software expects the RS-485 port with Modbus slave communication
protocol is configured to support the Modbus communication protocol
(2) the submenu is visible on condition that the application software expects the RS-485 port with Modbus master communication
protocol is configured to support the Modbus communication protocol
(3) the parameter is meaningful on condition that the RS-485 port is configured to support the Modbus master communication
protocol.
parameter available in read only modality
parameter available in read only modality
parameter available in read only modality
parameter available in read only modality
page 45 of 62
c-pro 3 micro and c-pro 3 kilo | Hardware manual ver. 1.0 | Code 114CP3UKE104
number of packages in reception
reading the power supply voltage of the
ratiometric transducers
reading the power supply voltage of the
0-20 mA / 4-20 mA / 0-10 V transducers
reading the power supply voltage coming
from the upper board
