- Page 1 INSTALLATION MANUAL FLOSTOP BUBBLERS 90˚ Bubbler TFT8000, TFT8000L 45˚ Bubbler TFT8050 Bubbler with separate button TFT8020 Up Right Bubbler TFT8050UR, TFT8050URL...
-
Page 2: Table Of Contents
Contents Product Features Product Range Technical Drawings Unit Components Installation Instructions Maintenance Time Adjustment Instructions Water Flow Adjustment Product Warranty... -
Page 3: Product Features
Flostop Bubblers by Gentec The FLOSTOP Soft close, timed flow product range is anti-vandal and has been designed to withstand heavy use in any commercial application for over 1.000.000 cycles of operation. The hydraulically operated time flow tapware will enhance your facility by providing high-level hygiene and extensive energy and water savings. -
Page 4: Product Range
Product Range TFT8000 / TFT8000L TFT8020 90° BUBBLER WITH PROTECTIVE GUARD BUBBLER WITH SEPARATE PUSH BUTTON TFT8050 TFT8050UR / TFT8050URL 45° BUBBLER WITH PROTECTIVE GUARD UP RIGHT BUBBLER WITH PROTECTIVE GUARD *Use 350Kpa pressure reducing valve for extended life and better operation... -
Page 5: Technical Drawings
Technical Drawings TFT8000 90° BUBBLER WITH PROTECTIVE GUARD 32.5 Ø30 32.5 TFT8020 BUBBLER WITH SEPARATE PUSH BUTTON G1/2 Ø44.5 W26x19 Ø30 W26X19 Ø33 G1/2 Ø44.5 G1/2 W26x19 W26X19 Ø33 *Regular service must be carried out on the product to avoid product failure. - Page 6 Technical Drawings TFT8050 45˚BUBBLER WITH PROTECTIVE GUARD TFT8050UR UP RIGHT BUBBLER WITH PROTECTIVE GUAR 49.5 Ø25 55.8 G1/2 GENTECH A *Use 350Kpa pressure reducing valve for extended life and better operation...
-
Page 7: Unit Components
Unit Components Description Description O Ring Bubbbler Guard Body Locking Screw Flow Cup Screw for water control adjustment Cartridge Handle Flow Regulator Cover Screw Strainer *Regular service must be carried out on the product to avoid product failure. www.gentecaustralia.com.au... -
Page 8: Installation Instructions
Installation Instructions BUBBLERS TFT8000, TFT8050, TFT8050UR, TFT8050URL For all Units: Flush the new pipe prior to installation. Bubblers should be installed with isolating stop tap valve. Install the Flow regulator and place the strainer in the inlet connection before screwing the valve to the water inlet. - Page 9 BUBBLER WITH SEPARATE PUSH BUTTON TFT8020 Allow a 32mm cut-out hole to fit the Figure3 push activated button mechanism. Drill a 3mm hole to fit the Anti-vandal pin. This should be fixed to prevent movement of the button. Fit the flexi hoses (not provided) to the water inlet and outlet.
-
Page 10: Maintenance
Maintenance Important Note For adequate maintenance, please unscrew and clean the strainer, then proceed to flush the line before putting back the strainer. O Ring Kit service For the following steps, a qualified plumber must be in charge of the maintenance and handling of the tapware in order to keep product Warranty. - Page 11 Remove the head valve using a shifter on the flats and remove the cartridge. (Figure 1) Undo the stopper (10) Set aside the crown ring (8) Set aside the head valve (5) from the stem Remove the washer Gaco (6) from the Figure1 head valve (5) and replace with the new washer gaco (6)
-
Page 12: Time Adjustment Instructions
Time Adjustment ADJUSTABLE CARTRIDGE (0 TO 40 SECONDS) This option is suitable for the following references: TFT8000, TFT8050, TFT8050UR, TFT8050URL • Turning the screw anti clockwise will The adjustable cartridge used is a 30mm increase the run time diameter handle with a small 3mm hole in the front of the handle. -
Page 13: Water Flow Adjustment
WATER FLOW ADJUSTMENT This option is suitable for the following references: TFT8000, TFT8050, TFT8050UR To adjust the water flow: Unscrew the top cap (6) (7) Remove the locking screw (8A) and adjust the flow with adjustable screw (8B) using a 3mm Allen key. -
Page 14: Product Warranty
Warranty GENTEC PRODUCT QUALITY WARRANTY You have purchased a quality product from GENTEC 2.2.7 include pictures of the alleged defect; in a Australia Pty Ltd ABN 581 552 50285 ). This product is reasonable time. covered by a 10 year replacement product warranty and a 24 month warranty on spare parts and labour. - Page 15 Law. You are entitled to a replacement or refund 4.3.1 an act, default, omission or representation for a major failure and compensation for any made by some other person, excluding Gentec other reasonably foreseeable loss or damage. or its manufacturer (for example, damage...
- Page 16 the Principal in relation to specific Goods. 5.3 The address for any notice to be delivered to the Principal is as follows: 4.5 However, nothing in this clause will prevent You from exercising any rights which You may have under the Competition and Consumer Act 2010 or any other law which cannot by law be excluded or modified by agreement.
