USER MANUAL
FLOSTOP Lead Free Brass
Valves
•
TFTLF1010 - Lead Free DZR Brass Wall
Mounted Single Temperature Timed
Flow Control Valve
•
TFTLF1010ADJ - Lead Free DZR Brass
Wall Mounted Shower/control Valve w/
Concealed Connection
•
TFTLF1016 - Lead Free DZR Brass In-
Wall Hot and Cold Temperature Timed
Flow Shower Mixer w/ Concealed
Stainless Steel Enclosure
•
TFTLF1015KIT - Lead Free DZR Brass
In-Wall Single Temperature Timed
Flow 15mm Male Shower Set w/ Recess
Stainless Steel Enclosure
•
TFTLF3500 - Lead Free DZR Brass Wall
Mounted 15mm Male Knee Operated
Valve w/ Knee Wand Attachment
•
TFTLF3500KIT - Lead Free DZR Brass
Wall Mounted Single Temperature
Timed Flow Knee Operated Valve w/
Knee Wand Attachment and Fixed
Basin Spout
MAR-IM-TFTLFV01-JT-20241223
gentecaustralia.com.au
Last updated in December 2024
AS 3718
Lic WM 74827
ApprovalMark
Advertisement
Table of Contents
Related Manuals for Gentec FLOSTOP TFTLF1010
Summary of Contents for Gentec FLOSTOP TFTLF1010
- Page 1 USER MANUAL FLOSTOP Lead Free Brass Valves • TFTLF1010 - Lead Free DZR Brass Wall Mounted Single Temperature Timed Flow Control Valve • TFTLF1010ADJ - Lead Free DZR Brass Wall Mounted Shower/control Valve w/ Concealed Connection • TFTLF1016 - Lead Free DZR Brass In- Wall Hot and Cold Temperature Timed Flow Shower Mixer w/ Concealed Stainless Steel Enclosure...
-
Page 2: Table Of Contents
USER MANUAL Table of Contents Scope of Use Technical Information Exploded Drawings Product Images & Technical Drawings Installation Steps Time Adjustment Cleaning & Maintenance Spare Parts Troubleshooting Water Quality Responsibly Sourced Scope of Use Installation of all products should adhere to the manufacturer's guidelines, as well as comply with PCA, AS/NZS3500 standards, and any other relevant regulatory provisions. -
Page 3: Technical Information
Technical Information • TFTLF1010, TFTLF1010ADJ, TFTLF3500, TFTLF3500KIT : Lead Free Brass Material • TFTLF1015KIT, TFTLF1016 : Valve- Lead Free Brass, Enclosure- Stainless Steel Cartridge Timed Flow (Hydraulic) Cartridge Size 15mm Inlet 15mm Male (G 1/2" BSP) Outlet 15mm Male (G 1/2" BSP) •... -
Page 4: Exploded Drawings
nit components USER MANUAL KNEE OPERATED VALVE KNEE OPERATED VALVE Exploded Drawings TFTLF3500KIT Item# Description Spare Parts Headvalve Holder TFT1015KIT Plastic Lever Knee Wand TFT1015KIT Flat Brass Spacer Spring Cartridge Flow Cup Valve Body Fixing Screws Flange Wall Plugs Strainer Preventative Maintenance O-Ring Kit (TFT9060) Pressure exceding 450 kPa will void warranty... - Page 5 TFT1015KIT TFTLF1015KIT *Pressure exceding 450 kPa will void warranty Item# Description Spare Parts *Pressure exceding 450 kPa will void warranty Plastic Cover Ring Cover Plate Grub Screws Fixing Screws Adjustment Cover Valve Body Wall Fixing Screws In-wall Box Wall Plug Preventative Maintenance O-Ring Kit (TFT9060) Note: Item 2 - 5 &...
-
Page 6: Product Images & Technical Drawings
All dimensions are in mm unless This drawing is property of PRODUCT RANGE specified and are to be used as LAST UPDATE APPROVED BY Gentec Australia Pty Ltd GPURE CLEANLINE a guide only 18/04/2024 SCALE 1/2" BSP TFTLF1010ADJ PRODUCT CODE... - Page 7 PRODUCT RANGE speci ed and are to be used as a guide only LAST UPDATE APPROVED BY Gentec Australia Pty Ltd GPURE CLEANLINE TFTLF1015KIT 10/12/2024 SCALE Lead Free DZR Brass In-Wall Single Temperature Timed Flow 15mm Male Shower Set w/ Recess Stainless Steel Enclosure gentecaustralia.com.au...
- Page 8 All dimensions are in mm unless This drawing is property of PRODUCT RANGE specified and are to be used as LAST UPDATE APPROVED BY Gentec Australia Pty Ltd GPURE CLEANLINE a guide only 18/04/2024 TFTLF3500 SCALE Lead Free DZR Brass Wall Mounted 15mm Male Knee Operated Valve w/ Knee Wand Attachment G1/2”...
-
Page 9: Installation Steps
SINGLE TEMPERATURE STRAIG TFT1010, TFT1010ADJ Installation Steps Flush the new pipe prior to installation Install the strainer. BEFORE THE SET UP • Valves must be installed to the button on the valve body is aligned requirements of AS/NZ 3500 by a with the water flow direction. - Page 10 LAST UPDATE APPROVED BY This drawing is property All dimensions are in mm unless of Gentec Australia Pty Ltd It is recommended to use flat union specified and are to be used as the arrow on the valve body is...
-
Page 11: Installation Instructions
To finish off the installation, fit rubber to Wall Installation Diagram the stainless-steel front cover plate Installation Instructions Waterproofing Tiling FOOT OPERATED VALVES Installation Instructions TFT3600 Step 6. Attach the adjustment cover (5) Step 8. The stainless-steel cover plate Fix Stai Steel b to the box, ensure adequate comes with two grub screws. - Page 12 KNEE OPERATED VALVE TFT3500, TFT3500KIT KNEE OPERATED VALVE Knee Valve Installation USER MANUAL TFT3500, TFT3500KIT Knee Valve Installation Screw the flange and knee valve into Place the flat brass nipple spacer on place using the necessary screws to the spring. Ensure the nipple is facing mount firmly onto the wall.
-
Page 13: Time Adjustment
40sec Fixed Timing Adjustment Increase the Fixed Timing Adjustment run time 40sec Please contact GENTEC before changing • Turning the screw in clockwise will • flow cups Turning the screw clockwise will Please contact GENTEC before changing •... -
Page 14: Cleaning & Maintenance
USER MANUAL Cleaning & Maintenance To minimise downtime and maximise the functional life of the product, GENTEC recommends servicing your product at least every 12 months, under heavy use may need to be checked and serviced more often. • The product must be handled carefully to avoid causing any physical damage. - Page 15 PRODUCT RANGE LAST UPDATE APPROVED BY This drawing is property dimensions are in mm unless of Gentec Australia Pty Ltd malfunction of the cartridge. ecified and are to be used as Step 10. Using the existing crown ring guide only SCALE place it back into the head valve.
-
Page 16: Spare Parts
USER MANUAL Spare Parts Product Description Components Included Code TFT9005 Hard Spring to suit TFT9069 1 x Hard Spring Extended Catridge to suit 1 x Button Handle, 1 x Catridge, 1 x O-Ring, 1 x TFT9012 TFT1015 Flow Cup Extended Catridge to suit TFT9013 1 x Extended Catridge TFT1016... -
Page 17: Troubleshooting
Troubleshooting Problem Cause How to Fix • Is the cartridge tight • Have you flushed the water line for a minimum of 1 minute before connecting the water • Have you installed the strainer and flow controller if provided • Debris • If debris or lubricants have gone through • Grease/ Tap is not the flow cup, it must be replaced. Debris or lubricant shutting off... -
Page 18: Water Quality
USER MANUAL Problem Cause How to Fix • Taps • Ensure the main pipe size is correctly sized Not enough installed in to provide adequate water to service the taps water a bank or a installed in a bank or a trough trough •... -
Page 19: Responsibly Sourced
GENTEC is rejuvenating the product- no power, less maintenance and longer life. Rejuvenation Program To learn more about the rejuvenation program, please contact our customer service at info@gentecaustralia.com.au for more information. Ethically and Environmentally Sourced Please refer to GENTEC Business Ethics & Ethical Sourcing Policy at https:// gentecaustralia.com.au/terms-and-conditions/ gentecaustralia.com.au... - Page 20 +612 9319 4422 +612 8088 7635 Gentec products come with a Manufacturer’s Warranty. To ensure the validity of this warranty, Gentec products must be installed following the provided installation instructions and adhering to AS 3500, NCC Volume Three, relevant Australian Standards, and any local authority requirements applicable to the product. Additionally, water and electrical supply conditions must meet the appropriate national and/or state standards.
