USER MANUAL
FLOSTOP Lead Free Brass
Bubbler
•
TFTLF8000 - Lead Free DZR Brass
Wall Mounted Right Angled Single
Temperature Timed Flow Bubbler w/
Safety Bubbler Guard
•
TFTLF8050 - Lead Free DZR Brass Wall
Mounted Angled Single Temperature
Timed Flow Bubbler w/ Safety Bubbler
Guard
•
TFTLF8050UR - Lead Free DZR
Brass Hob Mounted Upright Single
Temperature Timed Flow Bubbler w/
Safety Bubbler Guard
•
TFTLF8050URL - Lead Free DZR
Brass Hob Mounted Upright Single
Temperature Timed Flow Bubbler w/
Safety Bubbler Guard and Care Lever
Handle
Table of Contents
Scope of Use
Technical Information
Exploded Drawings
Product Images & Technical Drawings 4
Installation Steps
Time Adjustment
Water Flow Adjustment
Cleaning & Maintenance
Troubleshooting
Water Quality
Responsibly Sourced
MAR-IM-TFTLFB01-JT-20241223
