Valcom InformaCast VIP-142-IC Quick Start Manual

VIP-142-IC InformaCast® Compliant
High Power IP Talkback Paging Horn
INTRODUCTION
The VIP-142-IC IP Paging Horn is an
InformaCast compliant, weather-resistant, high-
efficiency horn supporting multiple audio and
control protocols, all delivered via a PoE-
enabled IP network. A separate microphone
facilitates full-duplex talkback communication.
The high-impact Polycarbonate construction
resists the deteriorating effects of outdoor
installation.
SPECIFICATIONS
Access Methods
• Singlewire InformaCast system
• SIP telephone system
• Valcom M Cast Page Group
• PBX, FXO Port w/VIP-811A
• POTS telephone set w/VIP-811A
• PBX, FXS Port w/VIP-821A
Features
•
InformaCast SIP compatible
•
Indoor / Outdoor use
•
High Impact Polycarbonate Housing
•
Omni-Directional Mounting Base
•
Built-in Microphone
•
SIP & Multicast Enabled
•
Power over Ethernet (PoE) 802.3af and
802.3at (PoE+) compatible
•
Remote Management & Monitoring
Dimensions / Weight
• 11.75" H x 10.0" W x 11.0" D (29.8cm H x
25.4cm W x 27.9cm D)
• 4.3 lbs. (1.95 kg)
Audio Codecs
• G.722, G.711 (uLaw, aLaw)
Frequency Response
• 350 Hz to 7kHz
Audio Dispersion
• 120° Horizontal
• 90° Vertical
Nominal Power Requirements
IEEE 802.3af (PoE)
IEEE 802.3at (PoE+)
These products are intended for use with a UL
Listed power source marked "Class 2" or "LPS"
rated 24 Vdc, or 48 Vdc (PoE).
PoE and all interconnected ITE are intended for
intra-building.
Environment
Temperature:
Humidity:
CAUTION
RISK OF ELECTRIC SHOCK
DO NOT OPEN
CAUTION: To reduce the risk of electric shock,
Do not remove cover (or back).
No user serviceable parts inside.
Refer servicing to qualified service personnel.
This symbol indicates that dangerous
voltage constituting a risk of electric
shock is present within this unit.
This symbol indicates that there are
important operating and maintenance
instructions in the literature accompanying
this unit.
1
Issue 1
Class 3
Class 4
- 20° to +50° C
0 - 95% non-condensing
947104
