Commissioning
9 Process signals
On the overview page of all online values
signals match the values from the system controller. The assignment of the channels is derived from the sensor con-
figuration page ("Sensor configuration" on page
Enter all the values in the startup report and calculate the percentage deviation as well.If the deviation is greater
than 10%, check the configuration.
The displayed values are the raw values of the respective signal such as mA for current, V for voltage and
Hz for RPM and therefore need to be converted.
E x a m p l e s f o r c o n v e r t i n g s i g n a l v a l u e s i n t o p r o c e s s v a l u e s
4..20mA signal
- Final value, generator power = 2.5 MW
- Signal value read off = 6.3 mA
- Process value calculated: 2.5 MW / 16mA * (6.3mA-4mA) = 0.36 MW
0-20mA signal
- Final value, signal value = see previous example
- Process value calculated: 2.5 MW / 20mA * 6.3mA = 0.79 MW
0-10V signal
- Final value, generator power = 2.5 MW
- Signal value read off = 6.3 V
- Process value calculated: 2.5 MW / 10V * 6.3V = 1.58 MW
Rotational frequency
- Number of trigger marks (lobes) = 5
- Frequency value read off = 28.6 Hz
RPM calculated: Revolutions/minutes = 28.6 Hz * 60 s/min / 5 = 343 RPM
E x a m p l e : C a l c u l a t i o n o f t h e p e r c e n t a g e d e v i a t i o n
Formula: <Percentage deviation> = 100% – (100% / <expected value> * <measured value>)
- (expected) value read off of the system controller: 0.39 MW
- Signal value displayed (converted): 0.36 MW
- Deviation in %: 100% - (100% / 0.39 MW * 0.36 MW) = 7.69 % < ±10 % -> o.k.
Ensure that you compare the values in the upper third of the measuring range if possible. A comparison
with very small values can lead to greater deviations due to the resolution being too low and due to signal
fluctuations!
21
("Sensor test" on page 19), check whether the values of the process
17).
