- Page 1 ASSEMBLY INSTRUCTIONS : 24 IN CHARLOTTE SWIVEL STOOL Description : S-312SW Item No. ITEM NO.: S-312SW Printed in Vietnam ISSUED NOV 15, 2017 - 1 -...
- Page 2 Remove all wrapping material, including staples & packing straps before you start to assemble. DO NOT tighten all screws, bolts until completely assembled. Keep all hardware parts out of reach of children. ASSEMBLY TOOLS REQUIRED NOT INCLUDED ITEM NO.: S-312SW Printed in Vietnam ISSUED NOV 15, 2017 - 2 -...
- Page 3 (M6 x 40mm) Lock Washer Flat Washer (6.5 x11mm) (6.5 x19mm) Long screw Short screw (M4 x 50mm) (M4 x 35mm) Allen Key (M4 x 30mm x 110mm) ITEM NO.: S-312SW Printed in Vietnam ISSUED NOV 15, 2017 - 3 -...
- Page 4 Attach the leg (C) to the leg (D) with bolts (2), and washers (3) and (4) as shown below. Tighten with Allen key (7). Place stretchers (E) between legs (C) and (D), attach with screws (5) as shown below. Tighten with a screwdriver. ITEM NO.: S-312SW Printed in Vietnam ISSUED NOV 15, 2017 - 4 -...
- Page 5 (3) and (4), as shown below. Tighten with Allen key (7). STEP 4 Attach the seat (F) to top of the seat frame (B) with screws (6). Tighten with a screwdriver. ITEM NO.: S-312SW Printed in Vietnam ISSUED NOV 15, 2017...
