Interface Signals

1 8 9
Figure B-1 32-Pin RJ-45 Connectors
Table B-1 Pin Descriptions for 32-Pin RJ-45 Connector: Channels 0 - 3
Description CH0
TD+ 1
TD– 2
RD+ 3
Not Used 4
Not Used 5
RD– 6
Not Used 7
Not Used 8
16 17 24
CH1 CH2
9 17
10 18
11 19
12 20
13 21
14 22
15 23
16 24
25 32
CH3
25
26
27
28
29
30
31
32
