set poInt (not adjustable In eMs Mode)

For ranges and Defaults, see Set Point Table
Button: MENU/Set Point
• The Set point is the pressure value the SQ-Elite-8S will use to control the system.
• The SQ-Elite-8S will add, subtract, or hold the stages of the heating boilers to maintain
the system pressure around the Set point.
• If the EMS Mode was Enabled, the Set Point will be set by the EMS/BMS system and
will be available as read only.

outdoor cutoFF teMperature

Adjustable Off, 20ºF/-7ºC - 100ºF/38ºC, On
Button: MENU/Outdoor Cutoff
• When the outdoor temperature falls to the adjustable Outdoor Cutoff temperature, the
SQ-Elite-8S will control and sequence the boiler stages to hold the set point.
• When the outdoor temperature rises to the Outdoor Cutoff plus a 2°F differential, the SQ-Elite-8S will turn all boilers off. The
System and Comb. Air relays that were energized will remain energized for the Run-On delay.
• The Outdoor Cutoff can be set to ON or OFF. In the ON position, the System Relay will run regardless of the Outdoor
temperature and the burner stages will be active to hold the set point.
• In the OFF position, the System Relay will always be off and all stages will be off as well.

setback

Adjustable 0°F/0°C to 80°F/44°C
Button: MENU/Setback
• The Setback feature can be used to provide the SQ-Elite-8S with a lower Set Point
when less load is required during the night or on the weekends when the building is not
occupied, but heat is still required.
• The new Set Point will appear on the main display indicating this condition "Setback to 5 Psi".
• For example, if the pressure set point is 8 Psi and the Setback is 3 Psi, then when in Setback, the SQ-Elite-8S will hold a Set
Point of 5 Psi.

day/nIgHt scHedules

Button: MENU/<System Settings>/<Setback Schedule>/Day Schedules
• The SQ-Elite has two levels of heat. The Day level is used when a building is occupied
and people are active.
• The Night (Setback) level is used when a building is not occupied, or when people are
sleeping. This setting reduces the set point by the Setback setting. If the Day calculated
pressure was 8 Psi and the Setback was 3 Psi, the Night Schedule will run at (8 Psi -
3Psi) = 5 Psi.
SQ-Elite-8S & SQ-Elite-EXT Installation Manual
In Set Point or EMS 4-20mA
Default: 70ºF/21ºC
in Set Point
Default: 0°F/0°C
----- SET POINT -----
