operatIng settIngs

Can be accessed by holding down the Menu button for over three seconds.

prograM cHange settIngs

To be able to change the SQ-Elite-8S settings the Program/Run Switch must be set to
Program. The switch is located under the Enclosure Wiring Cover for security The
Enclosure Wiring Cover can be securely closed using a padlock.

season

Winter, Summer
Button: MENU/Season
• The SQ-Elite-8S will turn all boiler relays off when it is in Summer setting. The
Message Display Line will read Summer to show status.
• When in Winter, the SQ-Elite-8S will activate the System relay whenever the Outdoor
temperature falls to or below the Outdoor Cutoff setting. In addition, it will begin
heating whenever the System pressure falls below the Set Point. The Message Display
Line will not display any season information.
• When the season is over, it is a good practice to switch the SQ-Elite-8S Season setting to
Summer to turn off all heating instead of turning off the control. This will preserve the
battery life.

set poInt (not adjustable In eMs Mode)

See pressure Transducer Default Settings and Ranges Table
Button: MENU/Set Point
• The Set point is the pressure value the SQ-Elite-8S will use to control the system.
• The SQ-Elite-8S will add, subtract, or hold the stages of the heating boilers to maintain
the system pressure around the Set point.
• The system can be expected to oscillate around the set point. The amount of oscillation depends on the System Settings and
Stage Settings.
• If an Outdoor Sensor was connected, pressing the SAVE button will switch to the Outdoor Cutoff setting option.
• If the EMS Mode was Enabled, the Set Point will be set by the EMS/BMS system and will be available as read only.
• Any value below the 2mA or above 22mA will indicate a "Shutdown by EMS" message on the Message Line.

outdoor cutoFF teMperature

Adjustable Off, 20ºF/-7ºC - 100ºF/38ºC, On
Button: MENU/Set Point/Outdoor Cutoff
• In Set Point mode, if the outdoor sensor is installed, the Outdoor Cutoff screen will
automatically appear after the pressure Set Point has been selected.
• When the outdoor temperature falls to the adjustable Outdoor Cutoff temperature, the SQ-Elite-8S will control and sequence the
boiler stages to hold the set point.
• When the outdoor temperature rises to the Outdoor Cutoff plus a 2°F differential, the SQ-Elite-8S will turn all boilers off. The
System and Comb. Air relays that were energized will remain energized for the Run-On delay then de-energize.
• The Outdoor Cutoff can be set to ON or OFF. In the ON position, the System Relay will run regardless of the Outdoor
temperature and the burner stages will be active to hold the set point.
• In the OFF position, the System Relay will always be off and all stages will be off as well.

systeM settIngs

Hold Button: MENU/<System Settings>
The System Settings menu provides access to adjusting and fine-tuning the heating system for
enhanced comfort and better fuel savings. The SQ-Elite-8S behaves differently based on the
selected Control Modes (see Startup Settings on page 14).
SQ-Elite-8S & SQ-Elite-EXT Installation Manual
Default: Winter
In Set Point or EMS 4-20mA
Default: 70ºF/21ºC
in Set Point
PROGRAM
alert
DO NOT turn power off to the
SQ-Elite when in off-season. If
you do so, the battery will run
down and have to be replaced.
Instead, switch to Summer.
---- SEASON ---
Winter
Summer
BACK
----- SET POINT -----
12.0psi
[
BACK
- OUTDOOR CUTOFF --
70 F
[
BACK
- SYSTEM SETTINGS -
<Stage Settings>
<Setback Schedule>
Setback 0.0Psi
Run-On
System Exercise Off
BACK SELECT
17
RUN
SAVE
]
SAVE
]
SAVE
2min
