General information

This manual describes the Emotron Softstarter MSF 2.0.
1.1 How to use the Instruction
Manual
This instruction manual tells you how to install and operate
the softstarter MSF 2.0. Read the whole Instruction Manual
before installing and putting the unit into operation.
Once you are familiar with the softstarter, you can operate it
from the control panel by referring to chapter 5. page 27.
This chapter describes all the functions and possible settings.
1.2

Integrated safety systems

The device is equipped with a protection system which
reacts to:
• Over temperature
• Voltage unbalance
• Over- and under voltage
• Phase reversal
• Phase loss
• Motor overload protection thermal and PTC.
• Motor load monitor, protecting machine or process
maximum or minimum alarm
• Starts per hour limitation
The softstarter is equipped with a connection for protective
earth (PE).
All MSF 2.0 softstarters are IP 20 enclosed types, except
MSF-1000 and MSF-1400 which are delivered as open
chassis IP00.
1.3

Safety measures

These instructions are a constituent part of the device and
must be:
• Available to competent personnel at all times.
• Read prior to installation of the device.
• Observed with regard to safety, warnings and informa-
tion given.
The tasks in these instructions are described so that they can
be understood by people trained in electrical engineering.
Such personnel must have appropriate tools and testing
instruments available. Such personnel must have been
trained in safe working methods.
The safety measures laid down in DIN standard VDE 0100
must be guaranteed.
The user must obtain any general and local operating per-
mits and meet any requirements regarding:
Emotron AB 01-4135-01r1
Q-Pulse Id TMS484
• Personnel safety
• Product disposal
• Environmental protection
NOTE! The safety measures must remain in force at all
times. Should questions or uncertainties arise, please
contact your local sales outlet.
1.4 Notes to the Instruction
Manual
NOTE: Additional information as an aid to avoiding
problems.
CAUTION: Failure to follow these instructions
can result in malfunction or damage to the
!
softstarter.
WARNING: Failure to follow these instructions
can result in serious injury to the user in addition
to serious damage to the softstarter.
Important
For all enquiries and spare parts orders, please quote the cor-
rect name of the device and serial number to ensure that
your inquiry or order is dealt with correctly and swiftly.
1.5

Type number

Fig. 1, page 5 gives an example of the type code number
used for an Emotron MSF Softstarter. With this code
number the exact type of the softstarter can be determined.
This identification will be required for type specific informa-
tion when mounting and installing. The code number is
located on the product label, on the front of the unit.
MSF -017
1 2
Fig. 1 Type number.
