9 Supplement
9.1 Technical data
General data
316L corresponds to 1.4404 or 1.4435, 316Ti corresponds to 1.4571
Materials
- Housing
- Ground terminal
- Inspection window of the indication
Weight
Ambient conditions
Ambient temperature
- without display
- with display
Storage and transport temperature
Electromechanical data
Cable gland
Screw terminals
Indicating and adjustment elements
Adjustment elements
Adjustment elements with display
Display (optional)
Adjustment circuit
Connection to
Connection cable to the sensor
Cable length
Voltage supply
Supply voltage
- without display
- with display
Q-Pulse Id TMS484
24
plastic PBT
316Ti/316L
approx. 0.5 kg (1.102 lbs)
-40 ... +85 °C (-40 ... +185 °F)
-20 ... +70 °C (-40 ... +158 °F)
-40 ... +85 °C (-40 ... +185 °F)
2 x cable entry M20 x 1.5 (cable-ø 5 ... 9 mm)
for wire cross-section up to 2.5 mm² (AWG 14)
2 x 2 keys, 2 x 1 rotary switch
2 keys, 1 rotary switch
LC multiple function display with bar graph (20
segments, digital value 4-digit), tendency in-
dicator for rising or falling values
VEGAWELL 72 4 ... 20 mA/HART, VEGABAR
74, VEGABAR 75
VEGA special cable with breather capillaries
max. 200 m
12 ... 36 V DC
17 ... 36 V DC
