PACKING LIST
ROWING MACHINE COMPONENTS
1.Frame
5.Front rail cover
9.Connecting sheet
13.Long sleeve x 2
PARTS LISTS
17.M10*55mm
18.M10 flat washer x 4
Allen bolt x 2
24.M10*55mm
23.M5*16mm bolt carriage bolt x 2
30.M8*20mm
29.Knob bolt
hex bolt x 4
2.Front foot pipe
6.Lock bolt set x 2
10.Rear rail cover
14.Left pedal
19.M10 split washer x 2
25.M10 acorn nut x 2
31.Big M8 flat
washer x 4
3.Rail
7.Seat
11.Rear foot pipe
15.Right pedal
20.M8*16mm
Allen bolt x 8
21.M8 flat washer x 8
26.M12*100mm
27.M12 lock nut
hex bolt
（13*15mm）
32.Allen wrench x 2
4.Frame connection
8.Rear support
12.Short sleeve x 2
16.Pedal pipe x 2
22.M8 split washer x 8
28.Detent pin
（17*19mm）
33.Open end wrench x 4
