Ruijie RG-S3250E Series Installation Manual page 8

Model
RG-S3250E-24
RG-S3250E-48
Module type
Ethernet 100M: FE-SFP-LX-MM1310
Ethernet 1000M: Mini-GBIC-SX
1000Base-T： Mini-GBIC-GT
Note: the supported module type may change at any time. For the detailed change information,
consult the Ruijie Networks.
Extended Module
M3000E-02SFP/GT
Type
M3000E-STACK
SFP Port
100Base-X
1000Base-X
Power supply
AC input:
Rated pressure range: 100-240V~
Maximum pressure range: 90-264V~
Frequency: 50-60Hz
Rated current: 2 A
Power
RG-S3250E-24: with extension modules < 27 W and without extension modules < 23 W
consumption
RG-S3250E-48: with extension modules < 38 W and without extension modules < 34 W
Temperature
Working temperature: 0ºC to 50ºC
Storage temperature: -40ºC to 70ºC
Humidity
Working humidity: 10% to 90% RH
Storage humidity: 5% to 90% RH
Fan
RG-S3250E-24：no fan
RG-S3250E-48：supports adjustment of fan speed and warning of fan trouble.
Temperature
Temperature warning function
Warning
EMC
GB9254-1998
Security
GB4943-2001
compliance
Dimensions (w x d
RG-S3250E-24: 440 x 260 x 44 mm
x h)
RG-S3250E-48: 440 x 300 x 44 mm
Weight
RG-S3250E-24: with extension modules 4.4 Kg and without extension modules 3.9 Kg
RG-S3250E-48: with extension modules 4.9 Kg and without extension modules 4.4 Kg
FE-SFP-LH15-SM1310
Mini-GBIC-LX
Mini-GBIC-LH40
Mini-GBIC-ZX50
Mini-GBIC-ZX80
Mini-GBIC-ZX100
