QuickSTART
This document provides a brief introduction to the CertusPro-NX Evaluation Board.
12 V DC Power Jack
Power LEDs
User LEDs
Main DC
Power Supply
SPI Flash
Mini USB
FTDI Chip
Potentiometer
1
Check Kit Contents
The CertusPro-NX Evaluation Board kit contains the following items:
CertusPro-NX Evaluation Board
„
12 V AC/DC Adapter and International Plug Adapters
„
USB Cable for Programming via PC (USB-A to Mini-B)
„
Quick Start Guide
„
Lattice Radiant software download information
„
2
Using the CertusPro-NX Evaluation Board
The CertusPro-NX Evaluation Board as shipped supports Master-SPI based
configuration. The external SPI Flash Configuration Memory is pre-loaded with a LED
blinking demonstration program.
CertusPro-NX Evaluation Board
SerDes SMAs
ADC Test
PMOD
Header
Connectors
DC Power Supply
I/O Extended Area
CertusPro-NX FPGA
FMC Connector
SMA1/SMA2
DIP Switch
Push Buttons
