Symmons Symmetrix S-20-BH Series Installation And Service Instructions

Lavatory Faucet
Installation and Service Instructions
Caution: Be sure to turn off hot and cold water supplies before
installing or servicing faucet.
Place gasket on base of faucet then loosely install the anchor
1.
bar (KN-23), spacer (KN-26) and nut (L-36) on the mount-
ing bolts. Push faucet supplies and anchor bolt/spacer/nut
assemblies with gasket through holes in sink. Secure faucet
to sink by tightening nuts from underside. (If sink or counter
surface is uneven, use putty or sealant to make proper seal
under base.)
2. Connect supply hoses to supply stops (left hose to hot, right
to cold). Hot hose is marked with tag. Note: If the LCT
handle is being used the supplies will be reversed. The right
side hose will be marked hot and should cross over and be
connected to the hot supply. Connect the left side hose to the
cold supply.

Pop-up drain installation:

3.
a) Remove pop-up plug, tail piece and flange from the drain
body. Make sure that locknut is threaded all the way
down onto the body with flat friction washer in middle
and beveled washer on top.
b) Apply plumbers putty or sealant to bottom of flange.
c) Install drain body through drain opening in lavatory and
screw flange onto the drain body making sure that the
threads are completely engaged for proper sealing and
strength of the connection. Apply joint compound to all
threaded parts to insure proper seal. Apply putty or teflon
tape to tail piece before attaching to drain body.
d) Tighten locknut to compress the beveled flange evenly
across the bottom of the drain opening taking care not to
over tighten the locknut, causing damage to the lavatory.
e) Remove one of two ball washers from inside the threaded
cavity. Insert pop-up plug and pivot rod into body. Add
one ball washer (the second ball washer should remain
inside the body) to the outside of the ball. Tighten the
retaining nut until the ball is seated on the internal and
external ball washers. Note: The pop-up plug can be
installed either in the removable or non-removable posi-
tion, depending on the location of the hole located in the
guide at the bottom of the plug.
f) Slide the pivot rod through one side of the spring clip,
then the appropriate adjustment hole and then other side
of the spring clip.
g) Insert lift rod through faucet housing and the top of the
lift strap and secure it in place by tightening the screw.
Note: To insure proper operation of lift rod and pop-up,
Symmetrix
S-20-BH Series
4. It is very important to thoroughly flush the supply lines to
prevent foreign matter, i.e. copper chips, sand, stones, etc.
from damaging the sealing surfaces of cartridge. Remove
aerator and turn valve handle on to full cold position, open
cold supply. Without closing, turn handle to full hot and
open hot supply. Let water run in hot only and cold only
positions long enough to flush supply lines thoroughly. Shut
off faucet and replace aerator. Check for leaks.
5. The handle limit stop can be set to limit handle turn to the
hot position. The limit mechanism is factory set to allow full
handle travel. To adjust the limit stop, turn handle to the full
hot position and lift handle to open faucet approximately
half way to obtain a smooth flow for correct initial tempera-
ture measurement.
6. If when faucet is on and in full hot position and water is too
hot, remove plug button (KN-157), loosen set screw (L-22)
and remove handle (KN-3RB, KN-3BRB or LN-135) or
plug button (T-33), screw (LN-171), and handle (LN-122).
Lift limit stop ring using a small flat head screw driver and
rotate counter clockwise to lower temperature. If water is
not hot enough, rotate clockwise (See Figure 1 on reverse
side). After correct temperature is achieved, reattach handle,
reversing procedure above.
Cartridge Replacement (KN-4)
1. Remove plug button (KN-157), loosen set screw (L-22) and
remove handle (KN-3RB, KN-3BRB or LN-135) or plug
button (T-33), screw (LN-171), and handle (LN-122).
2. Engage tabs in cartridge wrench (LN-34) with slots in
compression ring (KN-2) and use screwdriver in wrench
holes or pliers on wrench and turn counter clockwise until
compression ring engages with cap (LN-8). Continue turn-
ing counter clockwise so that cap/ring assembly is removed
from the body (LN-371BH). Remove cartridge and three
ring seal (KN-4). Install new cartridge while taking care to
maintain position of the three ring seal at the base of the
cartridge. Match posts in base of cartridge with alignment
holes in valve body during assembly. Reassemble faucet in
reverse fashion. Thread cap onto body firmly by hand. Do
not use a wrench which may damage the finish. Tighten
compression ring (KN-2) finger tight using the wrench (LN-
34) then 1/4 to 1/2 turn further. Set hot water limit stop in
accordance with installation step 5 above.
®
For California Residents
WARNING: This product contains chemicals known to
the State of California to cause cancer, birth defects, or
other reproductive harm.
some adjustment of the linkage may be required. There
are two possible adjustment points:
1) lift strap to lift rod and 2) lift strap to pivot rod.
:
