- Page 1 TAKER B30 TAKER 480-331 PRODUCT MANUAL...
-
Page 2: Table Of Contents
TABLE OF CONTENTS INTRODUCTION Taker B30 Reference Guide Physical Characteristics & Warnings BATTERY Battery Installation and Replacement Battery Life OPERATION Operational Modes FEATURES Kill Switch Pressure Switch Dual Settings Heavy Duty Braided Cable Replaceable Lens Retrofit INSTALLATION Shield Installation WARRANTY 10–11... -
Page 3: Taker B30 Reference Guide
TAKER B30 REFERENCE GUIDE SHIELD LIGHT REPLACEABLE LENS LED (3) BATTERY PACK (FRONT SIDE - PLACED AGAINST SHIELD) BATTERY POWER/KILL COVER TABS (2) SWITCH CABLE ENTRY 3M RECLOSABLE LOCATION FASTENER CONNECTING THE BATTERY PACK PRESSURE SWITCH CONNECTOR PRESSURE SWITCH LIGHT HEAD... -
Page 4: Physical Characteristics & Warnings
PHYSICAL CHARACTERISTICS Please read below before using the Taker B30 as it relays beneficial operating and safety information. SHIELD LIGHT (P/N 480-331) Light Head: 3.9 x 0.9 x 2.0 in (100 x 23 x 50 mm) DIMENSIONS (LxWxH) Battery Pack: 5.3 x 1.2 x 2.2 in (135 x 31 x 56 mm) WEIGHT 9.2 oz (261 g) -
Page 5: Battery Installation And Replacement
BATTERIES The Taker B30 uses two (2) 18650, four (4) CR123, or four (4) RCR123. Do not mix used and new batteries, different battery brands, or different types of batteries as this could damage your product or cause battery leakage or explosion. -
Page 6: Battery Life
BATTERY LIFE* MODE CR123 18650 LUMENS MOMENTARY 2.5 hours 4 hours CONTINUOUS ON 2.5 hours 4 hours TURBO-STROBE™ 4 hours 6.5 hours *Battery life may vary according to mode selected, battery quality and prevailing ambient conditions. OPERATIONAL MODES For MOMENTARY mode: Press and hold the Power/Mode Switch. While the Switch is depressed, the light will operate continuously . -
Page 7: Features
FEATURES POWER/KILL SWITCH The Taker B30 has a Power/Kill Switch located on the BOTTOM of the Battery Pack. This mechanism is used to shut down or disable the shield light. POWER/KILL SWITCH PRESSURE SWITCH (INCLUDED) The Taker B30 includes a Pressure Switch that allows the user to place it anywhere on the shield. -
Page 8: Dual Settings
FEATURES (CONT’D) DUAL SETTINGS The Taker B30 includes two mode settings: the ON/OFF SETTING and the TACTICAL SETTING. The ON/OFF SETTING simply allows the Light Head to turn ON and OFF . The TACTICAL SETTING allows you to choose from three (3) different Operational Modes: Momentary , Continuous On, and Turbo- Strobe™. -
Page 9: Shield Installation
SHIELD INSTALLATION PRESSURE SWITCH BATTERY PACK CABLE BALLISTIC SHIELD Place the shield in between the battery pack and Light Head. (The shield pictured is cut in half for this visual) LIGHT HEAD Clean the surface of the shield where the Battery Pack and Light Head will be placed. -
Page 10: Warranty
WARRANTY AND OTHER INFORMATION PRODUCT DURABILITY being used by a minor. Any FoxFury product should be operated at speeds safe enough to maneuver around surrounding obstacles. Do not use under the influence of drugs or alcohol. CARE/CLEANING Your FoxFury product is a professional LIMITED LIFETIME tool. -
Page 11: Contact Foxfury
CALIFORNIA PROPOSITION the end user to register their FoxFury Product at www.foxfury .com/pages/ warranty-registration. This product can expose you to chemicals including Lead and DEHP , THIS IS THE ONL Y WARRANTY , which are known to the State of EXPRESSED OR IMPLIED, California to cause cancer and birth INCLUDING ANY WARRANTY OF... - Page 12 FOXFURY .COM 12/2021...
