- Page 1 TRANSFORMER NOMAD ® ® 200-1200 | 200-1200-TC PRODUCT MANUAL...
-
Page 2: Table Of Contents
TABLE OF CONTENTS INTRODUCTION Reference Guide 3–4 Overview Physical Characteristics & Warnings 5–6 BATTERY Charging the Power Pack Charge Indicator OPERATION Operational Modes Battery Life Battery Life Indicator Using the Nomad while Plugged in ® Charging from a 12-24V Battery FEATURES Light Head Configuration Sliding Diffuser Lens (Area-Spot) -
Page 3: Reference Guide
TRANSFORMER REFERENCE GUIDE ® DEPLOYED VIEW SLIDING DIFFUSER LENS (3) (AREA-SPOT) LIGHT HEAD LOCKING RING/ CONNECTOR SWIVEL COVER ADJUSTMENT KNOB (340º) TRIPO-SCOPE ® POLES LEVEL BUBBLE TRIPO-SCOPE ® TIGHTENING RINGS BATTERY LIFE/ CHARGE INDICATOR PROTECTIVE LIGHT CAP TRIPO-SCOPE ® TIGHTENING RING CHARGING PORT/ DUST COVER STABILIZING FOOT... - Page 4 TRANSFORMER REFERENCE GUIDE ® STORED VIEW LIGHT HEAD BRAKE KNOB TIL T ADJUSTMENT KNOB NOMAD ® TRANSFORMER ® LEASH TRIPO-SCOPE LEGS ® (STORED POSITION) TRIPO-SCOPE ® BATTERY LIFE/ CHARGE INDICATOR REMOTE SWITCH INDICATOR REMOTE SWITCH POWER PACK POWER/MODE SWITCH ALSO INCLUDED Nomad Transformer Light Head Bag...
-
Page 5: Overview
OVERVIEW This ultimate scene light provides up to 16,000 lumens on HIGH power. Its portable, waterproof and self-contained design allows it to travel and be used in places that standard scene lights cannot reach. The Transformer comes ® in three (3) pieces (Light Head, Tripo-Scope , and Power Pack). -
Page 6: Charging The Power Pack
WARNINGS When used for extended periods of time the Nomad Light Head will ® become HOT to the touch. Please use care when operating. Do not stare into LEDs for long periods of time or from a close range (less than 2 ft (.06 m). Be sure to rinse the Nomad Transformer with fresh water immediately... -
Page 7: Charge Indicator
CHARGE INDICATOR (FOR LOCATION, PLEASE REFERENCE PAGE 3) COLOR DESCRIPTION GREEN (SOLID) FULL Y CHARGED GREEN (FLASHING) CHARGING RED (SOLID) CHARGING ERROR *If a charging error occurs, please contact FoxFury Customer Service (see pg. 22). OPERATIONAL MODES ON/LOW mode: Press the Power/Mode Switch once. MEDIUM mode: From LOW mode, press the Power/Mode Switch once. -
Page 8: Using The Nomad ® While Plugged In
USING THE NOMAD TRANSFORMER WHILE PLUGGED IN ® ® The Nomad Transformer can run continuously by plugging it into a power ® ® source. Start with the AC Cable. Plug it into a wall outlet or inverter. Plug the 5 PIN Connector into the Charging Port of the Nomad . -
Page 9: Features
FEATURES LIGHT HEAD CONFIGURATION The Nomad Transformer Light Head has the versatility to be used in a 360 ® ® or Directional configuration. DIRECTIONAL SLIDING DIFFUSER LENS (AREA-SPOT) Using the Sliding Diffuser Lens on the Nomad Transformer provides two ® ®... -
Page 10: Swivel And Tilt Light Head
FEATURES (CONT'D) SWIVEL AND TIL T LIGHT HEAD The Nomad Transformer Light Head has the versatility to swivel (via the Swivel ® ® Adjustment Knob) and tilt (via the Tilt Adjustment Knob). STABILIZING FOOT Release stabilizing foot to provide stabililty to the deployed triposcope. LEVEL BUBBLE On uneven ground, fine adjustments can be made by adding spacers under legs. -
Page 11: Ft Tripo-Scope ® Poles
12.9 FT TRIPO-SCOPE POLES ® The 12.9 ft height allows the Nomad Transformer to be deployed to reach ® ® over and illuminate most tall vehicles such as firetrucks and ambulances. REMOTE KEY FOB USE TO ACTIVATE THE REMOTE KEY FOB Press the Remote Switch on the light once and make sure the green indicator light is ON. -
Page 12: Nomad ® Transformer ® Leash
NOMAD TRANSFORMER LEASH ® ® The Nomad Transformer Leash (P/N 51- 034) can be used as extra security ® ® when the Transformer is used in high wind or with the Transformer Extension. ® ® BASE OF LIGHT HEAD AIR VENT NOMAD ®... -
Page 13: Deploying The Nomad
DEPLOYING THE NOMAD WITH NO ® TRIPO-SCOPE ® This method allows the unit to be quickly deployed and be used in very tight spaces or on table tops. Light Head can become HOT with use. Wear appropriate PPE/Gloves if touching the Light Head. Begin with the Light Head and Power Pack ONL Y . -
Page 14: Full Y Deploying The Nomad
FULL Y DEPLOYING THE NOMAD ® LEG LOCKS... - Page 15 Unscrew all three (3) Caps from the three (3) different parts of the Nomad ® Transformer (Light Head, Tripo-Scope , and Power Pack). ® ® Once all Caps are removed, place the Tripo-Scope onto the Power Pack ® (male end), line up the I, II, and III marks (shown on pg. 13). Once aligned, tighten the Locking Ring to secure the Tripo-Scope to the Power Pack.
-
Page 16: Deploying The Nomad ® With Extension
DEPLOYING THE NOMAD WITH ® OPTIONAL EXTENSION (P/N 85-600) This method allows the unit to be quickly deployed and be used in very tight spaces or on table tops. Begin with the Light Head, Power Pack, and the Nomad Transformer ®... -
Page 17: Transformer ® Height Guide
TRANSFORMER HEIGHT GUIDE ® The Nomad Transformer can be used as is, ® ® or with the extension. - Page 18 MAINTENANCE REMOVING THE SLIDING DIFFUSER LENS | 3 MINS (APPROX) Slide the Sliding Diffuser Lens back into the 'Area' setting (see "Light Head Configuration" on pg. 9 for more information). Find and remove the four (4) screws located on each side of it. Tilt the Sliding Diffuser Lens forward.
-
Page 19: General Maintenance Tips
GENERAL MAINTENANCE TIPS The Nomad Transformer reaches a full charge in approximately 8 hours. ® ® (Charge time may depend on ambient conditions and battery health). Keep the light fully charged at all times, so that it is ready for use in the event of an emergency . - Page 20 NOTES...
-
Page 21: Warranty
WARRANTY AND OTHER INFORMATION PRODUCT DURABILITY Lights are strong enough to cause damage to the human eye. Do not stare into LEDs for long periods of time or from a close range (less than 2 ft). IPX7 FoxFury , LLC is not responsible for any injury or damage caused CARE/CLEANING during the use of this product. -
Page 22: Contact Foxfury
Purchaser and the product that you purchased is not covered by this warranty . This limited warranty is VOID if this Product has been altered or modified in any way (including but not limited to attempted warranty repair without authorization from Foxfury and/or alteration/removal of the serial number). - Page 23 FOXFURY .COM 10/2018...
