TAKER B70
TAKER
480-600 | 480-670
PRODUCT MANUAL

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the TAKER B70 and is the answer not in the manual?

Questions and answers

Related Manuals for Foxfury Lighting Solutions TAKER B70

Summary of Contents for Foxfury Lighting Solutions TAKER B70

  • Page 1 TAKER B70 TAKER 480-600 | 480-670 PRODUCT MANUAL...

  • Page 2: Table Of Contents

    TABLE OF CONTENTS INTRODUCTION Taker B70 Reference Guide Physical Characteristics & Warnings BATTERIES Battery Installation and Replacement Battery Life OPERATION Operational Modes FEATURES Ambidextrous Light Activation Pressure Switch Individual LED Rows Dual Settings WARRANTY CONTACT FOXFURY...

  • Page 3: Taker B70 Reference Guide

    TAKER B70 REFERENCE GUIDE LIGHT HEAD (FRONT) LEDs (6) HANDLE (FRONT SIDE) GRIP KILL SWITCH PRESSURE SWITCH PORT HANDLE (BACK SIDE) BATTERY CAP (2) GRIP POWER/MODE SWITCH (2)

  • Page 4: Physical Characteristics & Warnings

    PHYSICAL CHARACTERISTICS Please read below before using the Taker B70 as it relays beneficial operating and safety information. LIGHT HEAD DIMENSIONS (WxH) 8.1 x 1.1 x 3.0 in (206 x 28 x 76 mm) WEIGHT 11.64 oz (330 g) HANDLE DIMENSIONS (WxH) 9.8 x 3.5 x 3.3 in (250 x 88 x 83 mm)

  • Page 5: Batteries

    BATTERIES The Taker B70 uses three (3) or six (6) CR123 batteries. As long as there are at least three (3) installed, the light will function. Using three (3) CR123 batteries decreases the battery life by half, but does not effect the light intensity .

  • Page 6: Battery Life

    For OFF or EXIT a mode: Press the Power/Mode Switch once. Then, continue following the directions above to progress to desired mode. The Taker B70 has a KILL SWITCH located on the right side of the Handle behind the Power/Mode Switch. This mechanism is a safety precaution to make sure the light does not turn on when not intended to.

  • Page 7: Features

    FEATURES AMBIDEXTROUS LIGHT ACTIVATION The Taker B70 includes two (2) Power/Mode Switches on both the left and right sides of the Handle. This allows users to toggle between modes using either hand. HANDLE (BACK SIDE) POWER/MODE POWER/MODE SWITCH SWITCH PRESSURE SWITCH (INCLUDED) The Taker B70 includes a Square Pressure Switch that allows the user to place it anywhere on the shield.

  • Page 8: Individual Led Rows

    FEATURES (CONT’D) INDIVIDUAL LED ROWS The LEDs of the Taker B70 operate on separate circuits, allowing a single row of LEDs to continue functioning if the other row is damaged. DUAL SETTINGS The Taker B70 includes two mode settings: the ON/OFF SETTING and the TACTICAL SETTING.

  • Page 9: Warranty

    WARRANTY AND OTHER INFORMATION PRODUCT DURABILITY LIMITED WARRANTY FoxFury, LLC (“FoxFury”) warrants to the purchaser of this product (“Buyer”) that for a period of two years following purchase, this product will be free from defects in material and workmanship and will function in substantial compliance with FoxFury’s CARE/CLEANING written specifications for this product...

  • Page 10: Contact Foxfury

    CONTACT FOXFURY FoxFury is not responsible for any damage incurred while in transit. FoxFury, LLC Oceanside, CA 92056 USA 3. Buyer will be required to Toll-Free: 844-FOXFURY show proof of purchase—NO Tel: 760.945.4231 EXCEPTIONS. Fax: 760.433.3650 Email: Service@FoxFury.com 4. Any modifications to light, cable or Web: FoxFury .com battery pack automatically voids all warranties on this product.
  • Page 11 NOTES...
  • Page 12 FOXFURY .COM 11/2020...
