- Page 1 TRANSFORMER NOMAD NOMAD ® ® 200-1200 | 200-1200-TC PRODUCT MANUAL...
-
Page 2: Table Of Contents
TABLE OF CONTENTS INTRODUCTION Reference Guide 3 – 4 Overview & Physical Characteristics Warnings BATTERY Charging the Power Pack Charge Indicator OPERATION Operational Modes Battery Life & Battery Life Indicator Using the Nomad while Plugged in ® Driving or Charging from a 12-24V Battery FEATURES Light Head Configuration Sliding Diffuser Lens (Area-Spot) -
Page 3: Reference Guide
TRANSFORMER REFERENCE GUIDE ® 1/4"-20 MOUNT DEPLOYED VIEW SLIDING DIFFUSER LENS (3) (AREA-SPOT) LIGHT HEAD LOCKING RING/ CONNECTOR SWIVEL COVER ADJUSTMENT KNOB (340º) TRIPO-SCOPE ® POLES LEVEL BUBBLE TRIPO-SCOPE ® TIGHTENING RINGS BATTERY LIFE/ CHARGE INDICATOR PROTECTIVE LIGHT CAP TRIPO-SCOPE ®... - Page 4 TRANSFORMER REFERENCE GUIDE ® STORED VIEW LIGHT HEAD BRAKE KNOB TIL T ADJUSTMENT KNOB NOMAD ® TRANSFORMER ® LEASH TRIPO-SCOPE LEGS ® (STORED POSITION) TRIPO-SCOPE ® BATTERY LIFE/ CHARGE INDICATOR REMOTE SWITCH INDICATOR REMOTE SWITCH POWER PACK POWER/MODE SWITCH ALSO INCLUDED Nomad Transformer Light Head Bag...
-
Page 5: Overview & Physical Characteristics
OVERVIEW This ultimate scene light provides up to 17,600 lumens on HIGH power. Its portable, waterproof and self-contained design allows it to travel and be used in places that standard scene lights cannot reach. The Transformer comes ® in three (3) pieces (Light Head, Tripo-Scope , and Power Pack). -
Page 6: Warnings
WARNINGS Please fully charge the Power Pack before using the Nomad ® Transformer for the first time. ® Do not stare into LEDs for long periods of time or from a close range (less than 2 ft or 0.6 m). When used for extended periods of time the Nomad Light Head will ®... -
Page 7: Charge Indicator
CHARGE INDICATOR (FOR LOCATION, PLEASE REFERENCE P . 3) COLOR DESCRIPTION GREEN (SOLID) FULL Y CHARGED GREEN (FLASHING) CHARGING RED (SOLID) CHARGING ERROR* *If a charging error occurs, please contact FoxFury Customer Service (see p. 21). OPERATIONAL MODES ON/LOW mode: Press the Power/Mode Switch once. MEDIUM mode: From LOW mode, press the Power/Mode Switch once. -
Page 8: Using The Nomad ® While Plugged In
USING THE NOMAD TRANSFORMER WHILE PLUGGED IN ® ® The Nomad Transformer can run continuously by plugging it into a power ® ® source. Plug the AC Power Cord of AC-DC Adaptor into a wall outlet or inverter. The 5 PIN Connector has a white dot. Make sure that it is pointing up. Plug the 5 PIN Connector into the Charging Port of the Nomad . -
Page 9: Features
FEATURES LIGHT HEAD CONFIGURATION The Nomad Transformer Light Head has the versatility to be used in a 360 ® ® or Directional configuration. DIRECTIONAL SLIDING DIFFUSER LENS (AREA-SPOT) Using the Sliding Diffuser Lens on the Nomad Transformer provides two ® ®... -
Page 10: Swivel And Tilt Light Head
FEATURES (CONT'D) SWIVEL AND TIL T LIGHT HEAD The Nomad Transformer Light Head has the versatility to swivel (via the Swivel ® ® Adjustment Knob) and tilt (via the Tilt Adjustment Knob). STABILIZING FOOT Release Stabilizing Foot to provide stabililty to the deployed Tripo-Scope ®... -
Page 11: 12.9 Ft (3.9 M) Height
12.9 FT (3.9 M) HEIGHT The 12.9 ft (3.9 m) height allows the Nomad Transformer to be deployed to ® ® reach over and illuminate most tall vehicles such as firetrucks and ambulances. REMOTE KEY FOB USE TO ACTIVATE THE REMOTE KEY FOB Press the Remote Switch on the Power Pack once and make sure the green indicator light is ON. -
Page 12: Nomad Transformer Leash
NOMAD TRANSFORMER LEASH ® ® (P/N 51-034) The Nomad Transformer Leash can be used as extra security when the ® ® Transformer is used in high wind or with the optional Transformer Extension ® ® (P/N 85-600). BASE OF LIGHT HEAD AIR VENT NOMAD ®... -
Page 13: Deploying The Nomad
DEPLOYING THE NOMAD WITH NO ® TRIPO-SCOPE ® This method allows the unit to be quickly deployed and be used in very tight spaces or on table tops. Begin with the Light Head and Power Pack ONL Y . Remove the two (2) Caps from the Light Head and Power Pack (for location see p. -
Page 14: Full Y Deploying The Nomad
FULL Y DEPLOYING THE NOMAD ® LEG LOCKS... - Page 15 Unscrew all three (3) Caps from the three (3) different parts of the Nomad ® Transformer (Light Head, Tripo-Scope , and Power Pack). ® ® Once all Caps are removed, place the Tripo-Scope onto the Power Pack ® (male end), line up the I, II, and III marks (shown on p. 13). Once aligned, tighten the Locking Ring to secure the Tripo-Scope to the Power Pack.
-
Page 16: Deploying The Nomad ® With Extension
DEPLOYING THE NOMAD WITH ® OPTIONAL EXTENSION (P/N 85-600) This allows for a 7.3 ft (223 cm) tall unit that could be used in a more confined space. Begin with the Light Head, Power Pack, and the Nomad Transformer ® ®... -
Page 17: Transformer Height Guide
TRANSFORMER HEIGHT GUIDE ® The Nomad Transformer can be used as is, or with the extension. ® ®... -
Page 18: Maintenance
MAINTENANCE REMOVING THE SLIDING DIFFUSER LENS 3 MINS ESTIMATED Slide the Sliding Diffuser Lens back into the 'Area' setting (see "Light Head Configuration" on p. 9). Find and remove the four (4) screws located on each side of it. Tilt the Sliding Diffuser Lens forward. Pull the Sliding Diffuser Lens out and free from the Light Head. - Page 19 GENERAL MAINTENANCE TIPS The Nomad Transformer reaches a full charge in approximately 8 hours. ® ® (Charge time may depend on ambient conditions and battery health). Please DO NOT leave AC-DC Adaptor plugged into Nomad charged for ® more than eight (8) continuous hours. Maintain the light fully charged at all times, so that it is ready for use in the event of an emergency .
-
Page 20: Warranty
WARRANTY AND OTHER INFORMATION PRODUCT DURABILITY Lights are strong enough to cause damage to the human eye. Do not stare into LEDs for long periods of time or from a close range (less than 2 ft or 0.6 m). IPX7 FoxFury, LLC is not responsible for any injury or damage caused CARE/CLEANING... -
Page 21: Contact Foxfury
CONTACT FOXFURY This limited lifetime warranty is given only to the original end user of FoxFury , LLC the accompanying product. If you Oceanside, CA 92056 USA purchased a product from someone Toll-Free: 844-FOXFURY other than an authorized FoxFury Tel: 760.945.4231 reseller/distributor or if the product Fax: 760.433.3650 was used, (including but not limited... - Page 22 FOXFURY .COM 8/2021...
