SINGULARITY COMPUTERS PowerBoard PC-011D Installation Manual page 4

Specifications & Included Items
Connections
Included Items
Weight
Dimensions
Packaged Weight
Packaged Dimensions
Tools Required
Revision 1.0
• 24pin Input & Output
• 8pin EPS Inputs x2 Outputs x4
(A total of 7 EPS and PCIe outputs can be used at the same time).
• 8pin PCIe Inputs x5 Outputs x6
(A total of 7 EPS and PCIe outputs can be used at the same time).
• PWM Inputs x1 Outputs x7
• ARGB Inputs x1 Outputs x7
• SATA Data Inputs x2 Outputs x2
Please refer to documentation
wiring/pinouts.
• Fasteners:
o 6-32 x 0.25" Button Head Hex Black Steel: x8
o M3 x 4mm Button Head Hex Stainless Steel: x8
o M4 x 12mm Button Head Hex Stainless Steel: x4
o M4 x 6mm Button Head Hex Stainless Steel: x20
o M4 Female Stand Off Brass 10mm x 8
o M4 Female Stand Off Brass 50mm x 2
o M4 Male Threaded Standoff Brass 6.5mm (F) 10mm: x4
• Cables:
o 6-32 x 0.25" Button Head Hex Black Steel: x8
o M3 x 4mm Button Head Hex Stainless Steel: x8
0.05 kg
H: 395mm x W: 391.5mm x Thickness: 16mm
1 kg
W: 395mm x L: 430mm x H: 40mm
• M4 Allen Key
• M3 Allen Key
• 5mm Socket Driver
| SC PowerBoard PC-O11D Installation Manual
for full details on the connectors and
Page | 3
