T 80 sr PUMPED
electric shower
REGISTER ONLINE
ENTER A PRIZE DRAW
WIN
£100
LOVE2SHOP VOUCHERS
VISIT OUR WEBSITE TODAY
TRITONSHOWERS.CO.UK/REGISTER
PRODUCT REGISTRATION IS ONLY AVAILABLE
TO UNITS PURCHASED & INSTALLED IN THE UK
FOR YOUR SERVICE REFERENCE
NOTE DOWN THE PRODUCT CODE BELOW
(FROM THE FRONT OR TOP OF THE BOX)
ALTERNATIVELY REGISTER BY TEL: 024 7637 8321
Under *NO circumstances must this shower be connected directly to a mains
water supply. It is designed for GRAVITY FED COLD WATER systems ONLY !
*Failure to comply may invalidate product warranty
INSTALLATION AND OPERATING INSTRUCTIONS
Please read this book thoroughly and familiarise yourself with all instructions before commencing
installation and keep it for future reference.
The shower installation MUST be carried out by a suitably qualified person, in the sequence of
this instruction book.
IMPORTANT SAFETY ADVICE
The shower unit MUST BE switched off at the
isolating switch when not in use. This is a
safety procedure recommended for all
electrical appliances.
The shower head and hose supplied with this
product are a safety critical part of your shower.
Failure to use genuine Triton parts may cause
injury and invalidate your guarantee.
! IMPORTANT !
2181649A - October 2021
T00353

Advertisement

Table of Contents
loading

Related Manuals for Triton T80sr PUMPED

Summary of Contents for Triton T80sr PUMPED

  • Page 1 The shower head and hose supplied with this product are a safety critical part of your shower. Failure to use genuine Triton parts may cause injury and invalidate your guarantee. ALTERNATIVELY REGISTER BY TEL: 024 7637 8321 ! IMPORTANT ! Under *NO circumstances must this shower be connected directly to a mains water supply.
  • Page 2 T80sr pumped INTRODUCTION - PLEASE READ PLEASE READ THIS IMPORTANT SAFETY INFORMATION Products manufactured by Triton are safe and without risk provided they are installed, used and maintained in good working order in accordance with our instructions and recommendations. ARNING: DO NOT operate shower if frozen, or suspected of being frozen.
  • Page 3 DO NOT operate the shower if water ceases to ow during use or if water has entered inside the unit because of an incorrectly tted cover. T80sr pumped IMPORTANT - PLEASE READ THESE WARNING: If restarting the shower immediately after stopping, be aware that a slug of GENERAL GUIDANCE NOTES BEFORE PROCEEDING hot water will be expelled for the rst few seconds.
  • Page 4 If water ceases to flow switch off the shower at Standards and Approvals the start/stop button and the isolating switch. Splashproof rating IPX4. Contact Triton Customer Experience team for Complies with the requirements of current British advice. and European safety standards for household If ever the water becomes too hot and you and similar electrical appliances.

  • Page 5: Table Of Contents

    Energy Efficiency Class Energy Efficiency (%) Annual Electricity Consumption (kWh) Sound Power Level (db) To check the product suitability for commercial and multiple installations, please contact Triton’s speci cation advisory service before installation. Please see back of book for contact information.

  • Page 6: Main Components & Entry Points

    T80sr pumped MAIN COMPONENTS Main components Fig.1 Inside unit (fig.1) Power supply DC motor Bleed screw Feed pipe Thermal safety cut-out (main) Terminal block Can and element assembly Power selector Pressure switch 10. Temperature valve 11. Solenoid valve 12. Earth connection 13.

  • Page 7: Electrical Requirements

    T80sr pumped ELECTRICAL REQUIREMENTS Fig.3 - Illustrative purposes only WARNING! W-006-A Triton Showers, THIS APPLIANCE MUST BE EARTHED Triton Road, Nuneaton, Warwickshire, CV11 4NR xxxx The installation, supply cable and circuit protection must conform with BS 7671 (IEE wiring regulations) and be suf cient for the amperage required.
  • Page 8 T80sr pumped A 45 amp double pole isolating switch with 9.3 In any event, it is essential that individual a minimum contact gap of 3mm in both site conditions are assessed by a competent poles must be incorporated in the circuit.

  • Page 9: Water Requirements

    Water requirements *Diagrammatic view – not to scale. *Fig.5 For illustration purposes only. WARNING! Under no circumstances must this Minimum capacity T80sr pumped shower be connected 114 litres (25 gallons) directly to the mains water supply. Cold water cistern Stop Gate...

  • Page 10: Installing The Shower

    T80sr pumped SITING OF THE SHOWER Siting of the shower WARNING! FOR EASE OF SERVICING, THE UNIT MUST The shower must not be positioned W-008-A ALWAYS BE MOUNTED ON THE SURFACE OF where it will be subjected to freezing TILED WALLS. NEVER TILE UP TO THE UNIT.

  • Page 11: Fiitting The Shower To The Wall

    T80sr pumped FITTING THE SHOWER TO THE WALL Fitting the shower to the wall Fig.7 WARNING! Check there are no hidden cables or pipes before drilling holes for wall W-005-A plugs. Use great care when using power tools near water. The use of a residual current device (RCD) is recommended.
  • Page 12 T80sr pumped If entry is required from the back, rotate the inlet Fig.10 elbow upwards and fit the supplied elbow to connect to the pipe (fig.10). Make sure the hole in which the pipe enters through the wall is filled in completely in order to stop any possible ingress of water into the cavity area.

  • Page 13: Plumbing Connections

    T80sr pumped PLUMBING CONNECTIONS Plumbing connections WARNING! Plumbing to be carried out before wiring The outlet of the shower acts as a DO NOT use jointing compounds on any pipe W-004-A vent and MUST NOT be connected to fittings for the installation.

  • Page 14: Electrical Connections

    T80sr pumped ELECTRICAL CONNECTIONS Electrical connections Fig.13 SWITCH OFF THE ELECTRICITY SUPPLY AT THE MAINS. Fig.13 shows a schematic wiring diagram. The cable entry points are shown in fig.1. The cable can be surface clipped, hidden or via 20mm conduit.

  • Page 15: Commissioning

    T80sr pumped COMMISSIONING Commissioning Fig.15 WARNING! Before normal operation of the W-001-A shower, it is essential the following commissioning procedure is completed correctly. IMPORTANT: Make sure the commission link is in the ON position - see fig.15. Commission ON Note: with the commission link in the ON = Pump OFF position with pump is OFF and will not operate.
  • Page 16 T80sr pumped Remove the cover and position the temperature Fig.16 control so that it points towards number 1 (fig.16). Position the power selector to the COLD position (fig.17). DO NOT remove the locking screw fitted to the power selector spindle (fig.18) – it can be removed only when the commissioning procedure has been completed.
  • Page 17 T80sr pumped Attached to the START/STOP button inside the Fig.20 cover is a two-wire lead. The socket on the end of this lead must be connected to the plug at the bottom of the right-hand side of the backplate (fig.20). NOTE: The plug and socket can only fit one way.

  • Page 18: User Operating Instructions & Functions

    T80sr pumped OPERATING THE SHOWER Operating the shower Fig.23 WARNING! Before normal operation of Power on indicator W-001-A the shower, it is essential the commissioning procedure has been completed correctly. To Start the Shower Pressing the START/STOP button switches on the pump allowing water to immediately flow through the unit.
  • Page 19 T80sr pumped Adjusting the Shower Temperature The shower temperature is altered by increasing or decreasing the flow rate of the water through the shower via the temperature control. After obtaining your preferred shower temperature, the number can be remembered as...
  • Page 20 T80sr pumped OPERATING FUNCTIONS Operating functions Fig.24 Power on indicator (fig.24) The power neon will light when the START/STOP button is pressed. This indicates that power is on Cold to the pump and power selector. Low Water Pressure Cut-out Should the water pressure fall below the...

  • Page 21: Cleaning The Filter - Installers & Service Engineers Only

    T80sr pumped INSTRUCTIONS FOR INSTALLERS AND SERVICE ENGINEERS ONLY Instructions for installers and service engineers only CLEANING THE INLET FILTER Fig.25 It is recommended that the filter is periodically cleaned in order to maintain the performance of the shower. It is essential that this operation is carried out by a competent person.

  • Page 22: Fault Finding/Troubleshooting

    T80sr pumped FAULT FINDING IMPORTANT: Switch off the electricity at the mains supply and remove the circuit fuse before attempting any fault nding inside the unit. Fault finding Problem Cause Action 1 Shower inoperable, 1.1 Interrupted power 1.1.1 Check if a general power cut. Check other no water flow when supply.
  • Page 23 T80sr pumped FAULT FINDING Problem Cause Action 5 During use, the 5.1 Interrupted power 5.1.1 See 1.1.1 and 1.1.2. water flow ceases supply. abruptly. 5.2 Solenoid valve 5.2.1 Switch off immediately. Have solenoid malfunction (pump checked by a competent electrician or contact still operates).
  • Page 24 SHOWER CONTROLS - QUICK USER GUIDE T80sr pumped To START or STOP your shower To start the shower, press the The power light start/stop button. will illuminate. To STOP the shower - press the Start/Stop button, then turn the Turn the T00353 isolator switch OFF.
  • Page 25 T80sr pumped WEEE Directive – Policy Statement As a producer and a supplier of electric showers, Triton Showers is committed to the protection of the environment via our own environmental policy and compliance with the WEEE directive. Triton Showers is fully registered with the Environment Agency under the following scheme: Repic: Producers take-back scheme (PTS), registration number WEE/EJ3466QV All our electric products are labelled accordingly with the crossed out wheeled bin symbol.
  • Page 26 T80sr pumped...
  • Page 27 T80sr pumped...
  • Page 28 Trade Installer Hotline: 024 7637 8344 Nuneaton www.tritonshowers.co.uk Warwickshire, CV11 4NR E-mail: serviceenquiries@tritonshowers.co.uk E-mail: technical@tritonshowers.co.uk Triton is a division of Norcros Group (Holdings) Limited Triton reserve the right to change product specifi cation without prior notice. E&OE. © TRITON SHOWERS 2021...
