Triton T80ZFF FAST-FIT Installation And Operating Instructions Manual

Triton T80ZFF FAST-FIT Installation And Operating Instructions Manual

Electric shower

Advertisement

Quick Links

T80Z FAST-FIT
electric shower
REGISTER ONLINE
ENTER A PRIZE DRAW
WIN
£100
LOVE2SHOP VOUCHERS
VISIT OUR WEBSITE TODAY
TRITONSHOWERS.CO.UK/REGISTER
PRODUCT REGISTRATION IS ONLY AVAILABLE
THIS OFFER IS NOT VALID OUTSIDE THE UK
TO UNITS PURCHASED & INSTALLED IN THE UK
FOR YOUR SERVICE REFERENCE
NOTE DOWN THE PRODUCT CODE BELOW
(FROM THE FRONT OR TOP OF THE BOX)
ALTERNATIVELY REGISTER BY TEL: 024 7637 8321
INSTALLATION AND OPERATING INSTRUCTIONS
Please read this book thoroughly and familiarise yourself with all instructions before commencing
installation and keep it for future reference.
The shower installation MUST be carried out by a suitably qualified person, in the sequence of
this instruction book.
IMPORTANT SAFETY ADVICE
The shower unit MUST BE switched off at the
isolating switch when not in use. This is a
safety procedure recommended for all
electrical appliances.
The shower head and hose supplied with this
product are a safety critical part of your shower.
Failure to use genuine Triton parts may cause
injury and invalidate your guarantee.
2180834T - April 2021
Patents: GB 2489547
GB 2495343
GB 2481878

Advertisement

Table of Contents
loading

Summary of Contents for Triton T80ZFF FAST-FIT

  • Page 1 The shower head and hose supplied with this product are a safety critical part of your shower. Failure to use genuine Triton parts may cause injury and invalidate your guarantee. ALTERNATIVELY REGISTER BY TEL: 024 7637 8321 INSTALLATION AND OPERATING INSTRUCTIONS Please read this book thoroughly and familiarise yourself with all instructions before commencing installation and keep it for future reference.
  • Page 2 INTRODUCTION - PLEASE READ PLEASE READ THIS IMPORTANT SAFETY INFORMATION Products manufactured by Triton are safe and without risk provided they are installed, used and maintained in good working order in accordance with our instructions and recommendations. ARNING: DO NOT operate shower if frozen, or suspected of being frozen.
  • Page 3 DO NOT restrict ow out of shower by placing showerhead in direct contact with your body. DO NOT operate the shower if water ceases to ow during use or if water has entered inside the unit because of an incorrectly tted cover. IMPORTANT - PLEASE READ THESE WARNING: If restarting the shower immediately after stopping, be aware that a slug of GENERAL GUIDANCE NOTES BEFORE PROCEEDING...
  • Page 4 DO NOT place items such as soap or shampoo bottles on top of the unit. Liquid could seep through the joint between the cover and backplate. To check the product suitability for commercial and multiple installations, please contact Triton’s specification advisory service before installation. Telephone:...
  • Page 5: Table Of Contents

    PLEASE USE THE FOLLOWING CHECK LIST TO AID YOUR INSTALLATION Tick off as you complete SECTION SECTION Check that the water supply will satisfy requirements ..........SECTION SECTION Check that water & cable entry points of the unit meet requirements ..... SECTION SECTION Check that the electric supply will satisfy requirements ..........
  • Page 6 CONTENTS Page INTRODUCTION IMPORTANT SAFETY INFORMATION & GENERAL GUIDANCE NOTES (please read) GENERAL ADVICE TO USERS - CLEANING ADVICE INSTALLATION CHECK LIST (PLEASE FOLLOW & COMPLETE) SPECIFICATIONS ...................... 7 DIMENSIONS & CABLE/WATER ENTRY POINTS ............8 ELECTRICAL REQUIREMENTS ................9 - 10 INSTALLING THE SHOWER ..............11 - 19 Siting of the shower ...................
  • Page 7: Specifications

    SECTION SECTION check list SPECIFICATIONS ELECTRICAL Nominal power - rating at 240V Nominal power - rating at 230V 7.5kW – (32A MCB rating) 6.9kW – (32A MCB rating) 8.5kW – (40A MCB rating) 7.8kW – (40A MCB rating) 9.5kW – (40A MCB rating) 8.7kW –...
  • Page 8: Dimensions & Cable/Water Entry Points

    SECTION SECTION DIMENSIONS & ENTRY POINTS check list Fig.1 DIMENSIONS 225mm 104mm Fig.2 ENTRY POINTS = Back = Others WATER Left: Bottom, Back, Top & Side. Right: Bottom, Back, Top & Side. = Back = Others CABLE Left: Bottom, Back & Top. Right: Bottom, Back &...
  • Page 9: Electrical Requirements

    Fig.3 - Illustrative purposes only WARNING! W-006-A Triton Showers, THIS APPLIANCE MUST BE EARTHED Triton Road, Nuneaton, Warwickshire, CV11 4NR xxxx The installation, supply cable and circuit protection must conform with BS 7671 (IEE wiring regulations) and be sufficient for the amperage required.
  • Page 10 SECTION SECTION Continued A 45 amp double pole isolating switch with 9.3 In any event, it is essential that individual a minimum contact gap of 3mm in both site conditions are assessed by a competent poles must be incorporated in the circuit. electrician in order to determine the correct cable size and permissible circuit length.
  • Page 11: Siting Of The Shower

    SECTION SECTION check list Installation - SITING OF THE SHOWER SITING OF THE SHOWER Mains electric supply The installation must be in accordance with (via double pole switch) Water Regulations/Bylaws - see page 7 for water specifications • If it is intended to operate the shower at pressures above the maximum or below Double the minimum stated, contact Customer...
  • Page 12 SECTION SECTION Continued IMPORTANT: Water regulations (fig.6) WARNING • It is required that the shower head be The shower MUST NOT be ‘constrained by a fixed or sliding attachment positioned where it will be so that it can only discharge water at a point subjected to freezing conditions.
  • Page 13: Plumbing Installation

    SECTION SECTION check list Installation - PLUMBING INSTALLATION PLUMBING INSTALLATION IMPORTANT INFORMATION Plumbing to be carried out before wiring The outlet of the shower acts as a vent • DO NOT use jointing compounds on any and must not be connected to anything pipe fittings for the installation.
  • Page 14: Electrical Installation

    SECTION SECTION check list Installation - ELECTRICAL INSTALLATION ELECTRICAL INSTALLATION NOTE: Deviations from the designated entry IMPORTANT: Switch off the electricity supply at the mains before proceeding. points will invalidate product approvals. The cable entry points are listed on page 8. •...
  • Page 15 SECTION SECTION Continued The backplate has removable top trims (top left Fig.9 and top right) that may be used for pipe entry Top pipe trims and two additional sections (top left and top right) that may ONLY be used as a ‘cut out’ for top electrical cable entry (fig.9).
  • Page 16 SECTION SECTION Continued but DO NOT fully tighten the screws at this Fig.10 stage. The fixing holes are elongated to allow for out of square adjustment after the plumbing connection has been completed. • Connect the mains water supply to the inlet DO NOT use excessive force when making the connection.
  • Page 17 SECTION SECTION Continued Fig.11 DO NOT DISCONNECT THE TOP WIRES Terminal Terminal block in block in left hand right hand entry entry position position Earth terminal 2 Earth terminal 1 Terminal block - left or right entry • Install the Earth cable to Earth terminal 1 or 2 to match the left or right terminal block The terminal block is factory assembled as a position.
  • Page 18: Fitting The Cover

    SECTION SECTION Continued • Fig.12 shows a schematic wiring diagram. IMPORTANT: When connecting the cable fully tighten the terminal block screws and make sure that no cable insulation is trapped under the screws. Loose connections can result in cable overheating. NOTE: The supply cable earth conductor must be sleeved.
  • Page 19 SECTION SECTION Continued A. With the cover off the shower turn the POWER selector spindle clockwise until the flat section is on the left hand side (fig.13). B. With the cover off the shower turn the stabiliser valve spindle fully clockwise until resistance is felt (fig.14).
  • Page 20: Commissioning Procedure

    SECTION SECTION !! IMPORTANT !! COMMISSIONING check list WARNING Fig.17 Power selector Before normal operation of the shower, it to COLD is essential the following commissioning procedure is completed correctly. COMMISSIONING PROCEDURE The first operation of the shower is intended to flush out any remaining unit debris and to make sure the heater unit contains water before the elements are switched on.
  • Page 21: User Operating Instructions & Functions

    SECTION SECTION check list USER OPERATING INSTRUCTIONS OPERATING THE SHOWER - (fig.19) Fig.19 Power selector Make sure the commissioning procedure has been carried out. To start the shower • Press the Start/Stop button and water will flow. High Cold To stop the shower •...
  • Page 22 SECTION SECTION Continued To adjust the shower temperature - Abnormal Safety cut-out Economy and High settings only The unit is fitted with a non-resettable thermal cut-out safety device. In the event of abnormal • The water temperature is altered by increasing operation which could cause unsafe temperatures or decreasing the flow rate of the water within the unit, the device will disconnect the...
  • Page 23: Cleaning The Filter - Installers & Service Engineers Only

    CLEANING THE FILTER Instructions for installers and service engineers only INSTRUCTIONS FOR INSTALLERS AND SERVICE ENGINEERS ONLY Instructions for installers and service engineers only CLEANING THE FILTER It is recommended that the filter is periodically cleaned in order to maintain the performance of the shower.
  • Page 24: Fault Finding/Troubleshooting

    FAULT FINDING/TROUBLESHOOTING IMPORTANT: Switch OFF the electricity at the mains supply and remove the circuit fuse before attempting any fault finding inside the unit. Problem Cause Action 1 Shower 1.1 Interrupted power 1.1.1 Blown fuse or circuit breaker. Check inoperable, no supply.
  • Page 25 FAULT FINDING/TROUBLESHOOTING Problem Cause Action 4 Water too cool 4.4 Electrical 4.4.1 Have unit checked by suitably qualified or cold. malfunction. electrician or contact Customer (continued) Experience. 4.5 Safety cut-out 4.5.1 Thermal safety cut-out device has operated. operated. Have the unit checked by a suitably qualified engineer or contact Customer Experience.
  • Page 26: Spare Parts

    Please have your model name available. WEEE Directive – Policy Statement As a producer and a supplier of electric showers, Triton Showers is committed to the protection of the environment via our own environmental policy and compliance with the WEEE directive.
  • Page 27: Shower Controls - Quick User Guide

    SHOWER CONTROLS - QUICK USER GUIDE To START or STOP your shower. The power light will illuminate. To start the shower, press the Start/Stop button. To STOP the shower - press the Start/Stop button, then turn the Turn the isolator switch OFF. main power isolator switch ON To alter the FLOW and Temperature of your shower - HEAT SETTINGS ONLY.
  • Page 28: Service Policy/Uk Guarantee

    Trade Installer Hotline: 024 7637 8344 Nuneaton www.tritonshowers.co.uk Warwickshire, CV11 4NR E-mail: serviceenquiries@tritonshowers.co.uk E-mail: technical@tritonshowers.co.uk Triton is a division of Norcros Group (Holdings) Limited Triton reserve the right to change product specifi cation without prior notice. E&OE. © TRITON SHOWERS 2021...
