Reference Information
Specifications
Video
Gain ................................................. Unity
Bandwidth ...................................... 350 MHz (-3 dB)
Video Input
Number/signal type ..................... 1 VGA-QXGA RGBHV, RGBS, RGsB,
Connectors ..................................... (1) 15-pin HD female (optional Mac/VGA
Nominal level ................................ 1.0 Vp-p for Y of component video and
Minimum/maximum levels ........ Analog: 0.3 V to 1.5 Vp-p with no offset at
Impedance ...................................... 75 ohms
Horizontal frequency .................... 15 kHz to 135 kHz
Vertical frequency .......................... 30 Hz to 150 Hz
Return loss ...................................... <-40 dB @ 5 MHz
Input coupling ............................... DC
Video Output
Number/signal type ..................... 8 or 12 (depending on model) RGBHV,
Connectors
P/2 DA8 Series .................. 8 female 15-pin HD
P/2 DA12 Series ................ 12 female 15-pin HD
Nominal level ................................ 1 Vp-p for Y of component video and
Minimum/maximum levels ........ 0.3 V to 1.5 Vp-p (follows input)
Impedance ...................................... 75 ohms
Return loss ...................................... <-40 dB at 5 MHz
DC offset ......................................... ± 5 mV with input at 0 offset
P/2 DA8 and P/2 DA12 • Reference Information
A-2
RsGsBs, HDTV component video, S-video,
composite video
adapters are available)
S-video, and for composite video
0.7 Vp-p for RGB and for R-Y and B-Y of
component video
0.3 Vp-p for C of S-video
unity gain
RGBS, RGsB, RsGsBs, HDTV component
video, S-video, composite video (follows
input type)
S-video, and for composite video
0.7 Vp-p for RGB and for R-Y and B-Y of
component video
0.3 Vp-p for C of S-video
