5.3 Data Port Specifications

5.3.1 Serial Ports

5.3.1.1 Copper Ports
Parameter
Baud Rate
Connector
Isolation
Table 9: Copper Port Specification
5.3.1.2 Fiber Optic Ports
Parameter
Mode
Connector
Typical Dist. (km)
Optical Wavelength (nm)
Cable Size
Core/Cladding (um)
Table 10: Fiber Optic Port Specification
NOTES:
1. Maximum segment length is greatly dependent on factors such as fiber quality, and
number of patches and splices. Please consult RuggedCom sales associates when
determining maximum segment distances.
©
2008 RuggedCom Inc. All rights reserved
All manuals and user guides at all-guides.com
Specifications
300 bps – 230 kbps
DB9 or RJ45
2.5 kV
Specifications
Multimode
ST
5
820
50/125
62.5/125
30
Notes
RMS 1-minute
