RuggedCom RuggedServer RS416 Installation Manual page 14

Terminal # Description
1 PS1 Live / +
2 PS1 Surge Ground
3 PS1 Neutral / -
4 Chassis Ground
5 PS2 Live / +
6 PS2 Surge Ground
7 PS2 Neutral / -
8 Relay NO Contact
9 Relay Common
10 Relay NC Contact
Table 3: RS416 Power terminal block connection description
©
2008 RuggedCom Inc. All rights reserved
All manuals and user guides at all-guides.com
PS1 Live / + is connected to the positive (+) terminal if the
power source is DC or to the (Live) terminal if the power
source is AC.
PS1 Surge Ground is connected to the Chassis Ground via
a jumper on the terminal block. Surge Ground is used as the
ground conductor for all surge and transient suppression
circuitry.
PS1 Neutral / - is connected to the negative (-) terminal if
the power source is DC or to the (Neutral) terminal if the
power source is AC.
Chassis Ground is connected to the Safety Ground
terminal for AC inputs or the equipment ground bus for DC
inputs. Chassis ground connects to both power supply surge
grounds via a removable jumper.
PS2 Live / + is connected to the positive (+) terminal if the
power source is DC or to the (Live) terminal if the power
source is AC.
PS2 Surge Ground is connected to the Chassis Ground via
a jumper on the terminal block. Surge Ground is used as the
ground conductor for all surge and transient suppression
circuitry.
PS2 Neutral / - is connected to the negative (-) terminal if
the power source is DC or to the (Neutral) terminal if the
power source is AC.
Normally open, failsafe relay contact.
Failsafe relay common contact.
Normally closed, failsafe relay contact.
14
Usage
Rev104
