Setup Guide
This guide provides basic instructions for an
experienced installer to set up and operate the
Extron® CSVEQ 100 D Line Driver.
C Installation and service must be performed
by authorized personnel only.
Step 1 — Turn off the line driver and
input/output devices
Turn the input and output devices off and unplug
their power cords. Verify that the line driver
is disconnected from the power source before
proceeding.
Step 2 — Attach video output cables
• Connect a composite video output device to the
g
green cable (
• Connect the luma of an S-video output device to
the white cable (
• Connect the chroma of an S-video output device
to the yellow cable (
Step 3 — Attach video input cables
• Connect a composite video input source to the
RCA video input connector (
• Connect an S-video input source to this 4-pin
mini DIN connector (
Step 4 — Connect audio input/output
• For audio output, wire a balanced or
unbalanced audio output device to the
3.5 mm, 5-pole, direct insertion captive
screw connector (
information on how to wire the audio
output connector.
• For audio input, connect an unbalanced
stereo audio source to the left and right
RCA connectors (
as shown in figure 2.
N The audio output
wiring and the audio
output jumper (
setting must match.
For best results,
wire the output for
balanced audio.
Tip (L)
Ring (R)
Sleeve ( )
Figure 2 – Audio input
wiring
).
g
).
g
).
b
).
c
).
i
). See figure 3 for
d
). Wire the connector
Set audio output jumper to stereo.
Left Tip (+)
f
Left Ring (-)
)
Sleeve (s)
Right Tip (+)
Right Ring (-)
Use either the left or the right channel.
Set audio output jumper to dual mono.
Tip (+)
Ring (-)
Sleeve
Figure 3 – Audio output wiring
CSVEQ 100 D
—
Power
LED
1
2
RCA
Video
Input
Audio
Output
6
Jumper
Video
7
Output
Audio
9
Output
Figure 1 – Front and rear panel view
Balanced Stereo
AUDIO
OUTPUT
CONFIG
JUMPER POSITION
OFF = DUAL MONO
ON = STEREO
Balanced Mono
AUDIO
OUTPUT
CONFIG
JUMPER POSITION
OFF = DUAL MONO
ON = STEREO
CAUTION
Do not tin the wires!
Front panel
S-VIDEO
IN
VIDEO IN
AUDIO IN
L R
Rear panel
CSVEQ 100 D
AUDIO
OUTPUT
CONFIG
JUMPER POSITION
OFF = DUAL MONO
ON = STEREO
AUDIO OUTPUT
Unbalanced Stereo
Set audio output jumper to stereo.
Left Tip (+)
Sleeve
Right Tip (+)
Unbalanced Mono
Use either the left or the right channel.
Set audio output jumper to dual mono.
Tip (+)
Sleeve
Connect the sleeve to ground
(Gnd). Connecting the sleeve to
a negative (–) terminal will
damage the audio output
circuits.
Wall Plate
Faceplate
S-video
3
Input
Audio
4
Input
Equalization
and Gain
Controls
5
8
Power
Connector
AUDIO
OUTPUT
CONFIG
JUMPER POSITION
OFF = DUAL MONO
ON = STEREO
AUDIO
OUTPUT
CONFIG
JUMPER POSITION
OFF = DUAL MONO
ON = STEREO
