I. Press the F1 (L-N) button to change to Rotate.
II. Connect as shown in Figure 6.4.4
III. Once connected, press the Test button to start measurement.
IV. When the voltage is measured and the L1, L2, and L3 are correctly connected to the
terminal, a
V. If the voltage is low or there is a voltage problem, a
VOLT
Rotate
Hz: 50.0Hz
TN-net
0
Figure 6.4.5 Phase sequence screen.
symbol is displayed, and if not connected correctly, the
400 V
L1-L2
401 V
L2-L3
399 V
L1-L3
0
0
0
symbol is displayed.
20
symbol is displayed.
