PARTS LIST
(DEMO BOARD DC2874A-A)
ITEM QTY REFERENCE
16 1 RG1
17 1 U5
Hardware: For Demo Board Only
1 12 E1-E3, E5, E12, E14-E17,
E19-E21
2 11 E4, E7, E10, E13, E18,
E22-E24, E26-E28
3 5 E6, E8, E9, E11, E25
4 1 JP1
5 4 MP1-MP4
6 5 MP5-MP9
7 10 MP10-MP19
8 5 MP20-MP24
9 1 XJP1
DEMO MANUAL DC2874A-A/
PART DESCRIPTION
RES., 20 OHMS, 1%, 1/16W, 0402, AEC-Q200
IC OPAMP BUFFER 20MHZ 8DFN
TEST POINT, TURRET, 0.064" MTG. HOLE, PCB
0.062" THK
TEST POINT, TURRET, 0.094" MTG. HOLE, PCB
0.062" THK
STUD, #10-32, FASTENER, 0.625" LENGTH
CONN., HDR, MALE, 1x3, 2mm, VERT, STR, THT
STANDOFF , NYLON, SNAP-ON, 0.25" (6.4mm)
CONN RING FLAT 8AWG #10 CRIMP
NUT, HEX, #10-32, BRASS
WASHER, #10, LOCK, EXT, TIN FINISH
CONN., SHUNT, FEMALE, 2 POS, 2mm
DC2874A-B/DC2874A-C
MANUFACTURER/PART NUMBER
VISHAY, CRCW040220R0FKED
ANALOG DEVICES, LT1010CDD#PBF
MILL-MAX, 2308-2-00-80-00-00-07-0
MILL-MAX, 2501-2-00-80-00-00-07-0
PENCOM, PR1422
WURTH ELEKTRONIK, 62000311121
KEYSTONE, 8831
MOLEX, 0192210223
PENCOM, NU1132
PENCOM, WA4526
WURTH ELEKTRONIK, 60800213421
