- Page 1 KA326800TX Kellis Kitchen Cart For assistance with assembly, contact: Southern Enterprises, Inc. Customer Service: 1-800-633-5096 Assembly Instructions service@seidal.com www.seifurniturestore.com PO#: Page | 1...
- Page 2 Kellis Kitchen Cart Parts List Please check packaging for all parts and hardware before discarding. Unpack and lay parts on clean, padded surface like carpet or a blanket. Check that you have all parts indicated. Call customer service if any hardware is missing. Before beginning assembly, carefully study the diagrams below and sort your hardware according to the pictures.
- Page 3 Quantity Quantity Quantity of 20 of 20 of 6 Cam Bolts Cam Locks Wood Dowels Dia. 5/16"x1-1/4" Quantity Quantity Quantity f 18 f 12 f 12 Bolt Dia. 1/4x1-1/4” L Spring Washer Dia.1/4” Flat washer Dia.1/4” x3/4” Quantity Quantity Quantity of 1 of 16 of 2...
- Page 4 Kellis Kitchen Cart Assembly Instructions Attach Towel rack (K) to Side Panels (2/3) using Bolts (N). Tighten Bolts (K) with Allen Wrench (G). Attach Wheels (L/M) to Side Panels (2/3) using Wrench (O). Figure 1 Align Cam Bolts (A) by hand. Insert Cam Locks (B) into corresponding holes on Middle Panel (6) &...
- Page 5 Attach the Side Panels (2/3) to Shelf Panel (9), Front and Back Panels (4/5), and Bottom Panel (10) with Bolts (D), Spring Washers (E), and Flat Washers (F). Tighten Bolts (D) with Allen Wrench (G). Figure 3 Align Cam Bolts (A) by hand. Insert Cam Locks (B) into corresponding holes on Middle Panel (6) &...
- Page 6 Attach Drawer Side Panels (12/13) to Drawer Back Panel (14) using Screws (H). Insert Drawer Bottom Panel (15) into grooves of Panels (12/13/14). Attach Drawer Front Panel (11) to assembled unit using Screws (H). Attach Knobs (I) to Drawer Front Panel (11) using Bolts (J).
- Page 7 Now your Kellis Kitchen Cart is ready to use! Figure 7 Page | 7...
-
Page 8: Parts Replacement Form
90 days of your receipt, we are under no obligation to provide parts or replacement merchandise. For product issues, please contact Southern Enterprises at 800-633-5096 (toll-free) / 972-869-0111 (Dallas), Mon-Fri 9am – 4pm CST, or email us at service@seidal.com. Please ask for customer service representative for issues involving damages or replacement parts.
