- Page 1 OC9665R0TX Sewing Table-White For assistance with assembly contact: Assembly Instruction Southern Enterprises Inc. Customer Service 1-800-633-5096 service@seidal.com www.seidal.com...
- Page 2 OC9665R0TX Sewing Table-White Parts List Please review all parts and hardware before disposing of any packaging. Call Customer Service if missing hardware. Do not return to store/retailer. Using a screw that is too long will cause damage. Before beginning assembly, separate each type of screw. Carefully study the screw diagrams below.
- Page 3 Quantity Quantity Quantity Of 11 Of 11 Of 28 Wood Dowel ∮ 8*30mm Cam Bolt ∮ 6.8*36mm Cam Lock ∮ 15*12 Quantity Quantity Quantity Of 12 Cover Large-Machine-screw1/4*2mm T-Bolt Quantity Quantity Quantity Of 4 Unlocking Caster Locking Caster Small-Machine-screw M5 Quantity Quantity Quantity...
- Page 4 OC9665R0TX Sewing Table-White Assembly Instruction Step 1: Put all parts on a soft surface to prevent scratches Tighten wood screws(11) through hinges(12) into predrilled holes on underside of large top panel and leaf panel(A,B) as shown. Step 2: Insert wood dowel(1) into...
- Page 5 Step 3: Insert wood dowels(1)into predrilled holes on holes on edges of parts(C,D,J) and fit into corresponding holes on right side panel(H).Insert T-bolts(6) into the holes on parts(C,D,J) and tighten large machine screw(5) through predrilled holes on right side panel(H) into T-bolts(6). Please note that if screws do not tighten, rotate T-bolts(6) so that threads of T-bolt are...
- Page 6 Step 5: Fit casters (7,8) on bottom edge on side panel (H,I) by using small machine screws (9) and screw nuts (10) Insert wood dowels (1) into predrilled holes on the inside of side panel (H,I) and fit into corresponding holes on ends of large shelf (E), bottom front stretcher(L),top stretcher(K) and back panel(F).
- Page 7 Step 6: Insert wood dowels(1) and can-bolts(2) into predrilled holes on underside of parts(A,B) and fit into corresponding holes on top edges of parts(H,I,J,K). Insert cam-locks(3) into big holes on parts(H,I,J,K) with slot for screwdriver facing outward. Rotate cam-locks(3) clockwise to secure cam-bolts(2).
- Page 8 90 days of your receipt, we are under no obligation to provide parts or replacement merchandise. Please contact Southern Enterprises at 800-633-5096 or in Dallas 972-869-0111/ 9am – 4pm Mon-Fri Central time if you have product issues or email us at service@seidal.com. Please ask for customer service representative for issues involving damages or replacement parts.
