- Page 1 HO9054A0TX HO9054B0TX Radcliff 2-Drawer Wood/Metal Desk For assistance with assembly contact: Southern Enterprises, Inc. Customer Service 1-800-633-5096 service@seidal.com Assembly Instructions www.seidal.com PO#:12993 Page 1...
- Page 2 Radcliff 2-Drawer Wood/Metal Desk You may receive extra hardware with your unit. Parts List Please check packaging for all parts and hardware before discarding. Unpack and lay parts on clean, padded surface like carpet or blanket. Check that you have all parts indicated. Call customer service if hardware is missing. Before beginning assembly, carefully study the diagrams below and sort your hardware according to the pictures.
- Page 3 Quantity Quantity of 9 of 8 Spring Washer Bolt: Dia5/16”x5/8”L Quantity Quantity of 8 of 1 Flat Washer Allen Wrench Care and Cleaning Instructions: Before using, wipe with a clean, dry cloth. Periodically apply furniture wax to renew Call customer service at 1-800-633-5096 the finish.
- Page 4 Take out all drawers from Cabinet (D) by hand as shown. Figure 1 Attach Cabinet (D) to underside of Top Panel (A) with Bolts (1), Spring Washers (2), and Flat Washer (3). Tighten Bolts with Allen Wrench (4) as shown. Figure 2 Page 4...
- Page 5 Attach Metal Side Frame (B) to assembled unit on figure 2 with Bolts (1) Spring Washers (2), and Flat Washers (3). Do not tighten Bolts all the way at this time. Attach Back Rail (C) to assembled unit and to Metal Side Frame (B) with Bolts (4), Spring Washers (2), and Flat Washers (3).
- Page 6 If the desk is not level, please adjust the adjustable foot pad by hand as shown. Your Radcliff 2-Drawer Wood/Metal Desk is ready for use. Figure 5 Parts Replacement Form Page 6 Page 4...
- Page 7 90 days of your receipt, we are under no obligation to provide parts or replacement merchandise. Please contact Southern Enterprises at 800-633-5096 or in Dallas 972-869-0111/ 9am – 4pm Mon-Fri Central time if you have product issues or email us at service@seidal.com. Please ask for customer service representative for issues involving damages or replacement parts.
