- Page 1 DN0988A0TX- Base DN0988B0TX – Glass Top For assistance with assembly, contact： Olivia Dining Table Southern Enterprises Inc. Customer Service 1-800-633-5096 Assembly Instructions service@seidal.com www.seidal.com PO#: Page 1...
- Page 2 Olivia Dining Table PARTS LIST Please check packaging for all parts and hardware before discarding. Unpack and lay parts on clean, padded surface like carpet or blanket. Check that you have all parts indicated. Call customer service if hardware is missing.
- Page 3 Quantity Quantity of 7 of 10 4pcs can get from Figure 1 4pcs can get from Figure 1 long bolt: Dia 1/4”*1-1/2”l spring washer Quantity Quantity of 1 of 10 4pcs can get from Figure 1 metal plate flat washer Quantity of 4 glass pad...
- Page 4 Olivia Dining Table Assembly Instructions Remove bolts (3), spring washers (4), and flat washers (5) with allen wrench (1) and remove connecting bar from the side frame (B). Don’t discard bolts (3), spring washers (4), and flat washers (5). Please keep them to be used in Figure 3.
- Page 5 Attach connecting bar (D) to assembled unit with long bolts (3), spring washers (4), and flat washers (5). Tighten all bolts (3) using allen wrench (1) as shown. Figure 3 Align the holes on the metal plate (6) with the base holes and insert short bolts (2), spring washers (4), and flat washers (5) into the holes.
- Page 6 Insert glass pads (7) into holes on top frame as shown on figure 4. If base is not level, please adjust the leg’s leveler by hand as shown. Figure 5 Place glass top (A) on each glass pad as shown in figure 5. Figure 6 Page 6...
- Page 7 Now your Olivia dining table is ready to use. Figure 7 Page 7...
- Page 8 If damages or missing parts are not reported within 90 days of your receipt, we are under no obligation to provide parts or replacement merchandise. Please contact Southern Enterprises at 800-633-5096 or in Dallas 972-869-0111/ 9am – 4pm Mon-Fri Central time if you have product issues or email us at service@seidal.com. Please ask for customer service representative for issues involving damages or replacement parts.
