- Page 1 KA327700TX MARTINVILLE KITCHEN For assistance with assembly contact： CART - White Southern Enterprises Inc. Customer Service 1-800-633-5096 Assembly Instructions service@seidal.com www.seidal.com...
-
Page 2: Parts List
MARTINVILLE KITCHEN CART - White Parts List Please review all parts and hardware before disposing of any packaging. Call Customer Service if missing hardware. Using a screw that is too long will cause damage. Before beginning assembly, separate each type of screw. Carefully study the Screw diagrams below. - Page 3 Quantity Quantity of 11 of 4 Barrel Nut Long Bolt ( M6 X 50 ) Quantity Quantity of 3 of 2 Small Bolt ( M6 X 40 ) Spring Washer Quantity Quantity of 2 of 4 Flat Washer Cam Bolt Quantity Quantity of 4...
- Page 4 Quantity Quantity of 11 of 2 Wood Button Castor With Lock Quantity of 2 Castor Without Lock Care and Cleaning Instructions: Before using, wipe with a clean, dry cloth. For replacement parts or questions, please Periodically apply furniture wax to renew Call Customer Service at 1-800-633-5096.
- Page 5 Martinville Kitchen Cart - White Assembly Instructions Attach Cam Bolts (F) into Table Top (1) and Bottom Panel (10) as shown. Tighten using Screwdriver. Figure 1 Attach Side Frame (R) (2) to Table Top (1) with Long Bolts (M6x50) (A). Tighten using Allen Wrench (L) provided.
- Page 6 Insert Center Panel (8) onto the attached Cam Bolts (F) on the unit and secure using Cam Locks (G). Tighten Cam Locks (G) using Screwdriver. Attach Front Apron (9) to Center Panel (8) as shown by using Short Bolt (M6 X 40) (C). Tighten using Allen Wrench (L) provided.
- Page 7 Attach Towel Bar (13) onto the unit as shown with Short Bolts (M6 X 40) (C), Spring Washers (D) and Flat Washers (E). Tighten using Allen Wrench (L) provided. Attach Castors With Lock (P) and Castors Without Lock (Q) as shown. Figure 5 Insert Metal Pins (H) into the unit as shown.
- Page 8 Attach Drawer Side Apron (R) (12B) and Drawer Side Apron (L) (12C) to Drawer Front (12A) as shown. Tighten using Wood Screw (N) with Screwdriver. Slide Drawer Bottom Panel (12E) into assembled unit. Place the Drawer Back Panel (12D) onto assembled unit. Tighten using Wood Screws (N) with Screwdriver.
-
