Presentation Switchers
NHD-SW-0501 | SW-0501-HDBT | SW-1001-HDBT
Application Programming Interface
Document
Revision:
Document Date:
Minimum
Supported
Firmware:
© Copyright 2018 WyreStorm Technologies |
v1.2 (See
Revision History
June 18
th
2018
SW-0501-HDBT: v3.2.0
SW-1001-HDBT:v1.0.0
NHD-SW-0501-HDBT: v3.2.0
WyreStorm.com
for Updates)
North America: 844.280.WYRE (9973) | UK/EMEA: +44 (0) 1793 343
Email:
Support@WyreStorm.com
Advertisement
Table of Contents
Related Manuals for Wyrestorm NETWORK HD NHD-SW-0501
Summary of Contents for Wyrestorm NETWORK HD NHD-SW-0501
- Page 1 Document v1.2 (See Revision History for Updates) Revision: Document Date: June 18 2018 SW-0501-HDBT: v3.2.0 Minimum Supported SW-1001-HDBT:v1.0.0 Firmware: NHD-SW-0501-HDBT: v3.2.0 © Copyright 2018 WyreStorm Technologies | WyreStorm.com North America: 844.280.WYRE (9973) | UK/EMEA: +44 (0) 1793 343 Email: Support@WyreStorm.com...
-
Page 2: Table Of Contents
3rd Party Device Control (RS-232 2 Port)................................15 Contacting Support..................................16 Revision History ..................................16 Publication Disclaimer ..................................17 © Copyright 2018 WyreStorm Technologies | WyreStorm.com North America: 844.280.WYRE (9973) | UK/EMEA: +44 (0) 1793 343 2 of 18 Presentation Switcher API | 180618-1621 Email: Support@WyreStorm.com... -
Page 3: Overview
Network Connection with Network Passwords ..........................Visit the Product Page on WyreStorm.com to download firmware and additional product information ......... © Copyright 2018 WyreStorm Technologies | WyreStorm.com North America: 844.280.WYRE (9973) | UK/EMEA: +44 (0) 1793 343 3 of 18... -
Page 4: Network Connections For Ip Control
Connection the switcher to a network using the appropriate ports as defined below. SW-0501-HDBT and NHD-SW-0501 Network Connection SW-1001-HDBT Network Connection © Copyright 2018 WyreStorm Technologies | WyreStorm.com North America: 844.280.WYRE (9973) | UK/EMEA: +44 (0) 1793 343 4 of 18... -
Page 5: Rs-232 Connections
3. RS-232 Connections WyreStorm recommends that all wiring for the installation is run and terminated prior to making connections to the switcher. Read through this section in this entirety before running or terminating the wires to ensure proper operation and to avoid damaging equipment. -
Page 6: Complex Method - Shared Port For Switcher And Remote Device Control
RS-232 ports on the control system. SW-0501-HDBT Single Control System Port SW-1001-HDBT Single Control System Port © Copyright 2018 WyreStorm Technologies | WyreStorm.com North America: 844.280.WYRE (9973) | UK/EMEA: +44 (0) 1793 343 6 of 18... -
Page 7: Communication Configuration
Navigate to: Start > Run. In the Run dialog box, enter cmd then click OK. © Copyright 2018 WyreStorm Technologies | WyreStorm.com North America: 844.280.WYRE (9973) | UK/EMEA: +44 (0) 1793 343 7 of 18... - Page 8 Enter user name root and press Enter. When the following screen information appears, connection to switcher is successful. API commands to control the switcher may be entered in the command-line interface. © Copyright 2018 WyreStorm Technologies | WyreStorm.com North America: 844.280.WYRE (9973) | UK/EMEA: +44 (0) 1793 343...
-
Page 9: Commands Strings
Note: Each value will be followed by a Y (Active) or N (inactive) Example Command: gbconfig --show --source-select Currently selected source Response: Example: HDMI3 Y © Copyright 2018 WyreStorm Technologies | WyreStorm.com North America: 844.280.WYRE (9973) | UK/EMEA: +44 (0) 1793 343 9 of 18 Presentation Switcher API | 180618-1621 Email:... -
Page 10: Set Audio Output Volume Level (Discrete)
Sets the volume level of AUDIO OUT port. Accepted Values: up | down Example Command: gbconfig --line-out=1 --level-up Response: none © Copyright 2018 WyreStorm Technologies | WyreStorm.com North America: 844.280.WYRE (9973) | UK/EMEA: +44 (0) 1793 343 10 of 18 Presentation Switcher API | 180618-1621 Email: Support@WyreStorm.com... -
Page 11: Query Audio Output Volume Level
Example Command: gbconfig –show --audio-in-bind Response: Returns the source as defined in Accepted Values. Example: HDMI2 © Copyright 2018 WyreStorm Technologies | WyreStorm.com North America: 844.280.WYRE (9973) | UK/EMEA: +44 (0) 1793 343 11 of 18 Presentation Switcher API | 180618-1621 Email: Support@WyreStorm.com... -
Page 12: Video Commands
[Value]=Output Resolution Example Command: Example: 1920X1080_60 Response: Query Audio Output Mute State for details. © Copyright 2018 WyreStorm Technologies | WyreStorm.com North America: 844.280.WYRE (9973) | UK/EMEA: +44 (0) 1793 343 12 of 18 Presentation Switcher API | 180618-1621 Email:... -
Page 13: Control Commands
N: Auto switching disabled Switcher Reboot Syntax: reboot Description: Reboots the switcher. Accepted Values: © Copyright 2018 WyreStorm Technologies | WyreStorm.com North America: 844.280.WYRE (9973) | UK/EMEA: +44 (0) 1793 343 13 of 18 Presentation Switcher API | 180618-1621 Email: Support@WyreStorm.com... -
Page 14: Restore Factory Defaults
Note: The switcher requires a manual reboot (cycle power) after restoring defaults. Accepted Values: Example Command: reset_to_default.sh Response: none © Copyright 2018 WyreStorm Technologies | WyreStorm.com North America: 844.280.WYRE (9973) | UK/EMEA: +44 (0) 1793 343 14 of 18 Presentation Switcher API | 180618-1621 Email: Support@WyreStorm.com... -
Page 15: 3Rd Party Device Control (Rs-232 2 Port)
Example Command: 00 00 00 00 00 00 00 00 00 00 00 00 17" Response: none © Copyright 2018 WyreStorm Technologies | WyreStorm.com North America: 844.280.WYRE (9973) | UK/EMEA: +44 (0) 1793 343 15 of 18 Presentation Switcher API | 180618-1621 Email: Support@WyreStorm.com... -
Page 16: Contacting Support
1.5 Source Switching Added ScreenLink Start Page Commands v1.0 - 151021-1044 - October 2016 Original Release © Copyright 2018 WyreStorm Technologies | WyreStorm.com North America: 844.280.WYRE (9973) | UK/EMEA: +44 (0) 1793 343 16 of 18 Presentation Switcher API | 180618-1621 Email: Support@WyreStorm.com... -
Page 17: Publication Disclaimer
WyreStorm reserves the right to change software, control codes and specifications without notice. WyreStorm will not be liable for any use of this information or any changes it may make to those products. The use of this information constitutes an agreement by the user to these limitations and exclusions. - Page 18 EMEA: Unit 22, Ergo Business Park, Swindon, Wiltshire, SN3 3JW, UK Tel: +44 (0) 1793 230 343 WyreStorm Technologies reserves the right to change the physical appearance or technical specification of this product at any time. Visit wyrestorm.com for the latest product information.
