SW-0501-HDBT / SW-1001-HDBT
Presentation Switcher/Scaler with Mic Input | CEC Control (1080p to 100m/328ft)
Application Program Interface (API)
Version:
v1
Release Date:
October 21, 2015
Thank you for choosing this WyreStorm product.
Please read these instructions carefully before installing to avoid complications later.
Copyright © 2015 WyreStorm Technologies |
wyrestorm.com
Advertisement
Table of Contents
Related Manuals for Wyrestorm SW-0501-HDBT
Summary of Contents for Wyrestorm SW-0501-HDBT
- Page 1 Presentation Switcher/Scaler with Mic Input | CEC Control (1080p to 100m/328ft) Application Program Interface (API) Version: Release Date: October 21, 2015 Thank you for choosing this WyreStorm product. Please read these instructions carefully before installing to avoid complications later. Copyright © 2015 WyreStorm Technologies | wyrestorm.com...
-
Page 2: Important! Safety Information
Do Not Hot swap HDMI or HDBaseT connections - Please insert and extract cables carefully with the power SWITCHED OFF. Power is passed along transmissions so connecting and disconnecting cables while powered can result in damage to circuitry or possible injury. 2 of 14 SW-0501-HDBT / SW-1001-HDBT Presentation Switcher/Scaler Application Program Interface (API) | 151021-1044... -
Page 3: Table Of Contents
Power Off (Sleep) CEC Enabled Device ................................10 Party Device Control (RS-232 2 Port)................................11 Restore Switcher to Factory Defaults................................... 11 Reboot the Switcher ........................................ 11 Publication Disclaimer ..............................12 Copyright © 2015 WyreStorm Technologies | wyrestorm.com 3 of 14... -
Page 4: Introduction
The following document contains the Application Program Interface (API) commands to control the SW-0501-HDBT / SW- 1001-HDBT presentation switchers via serial commands. Before Beginning WyreStorm recommends visiting the product page before installing this product for updates to this API as well as other information about the product. 4 of 14... -
Page 5: Wiring And Connections
2. Wiring and Connections WyreStorm recommends that all wiring for the installation is run and terminated prior to making connections to the switcher. Read through this section in this entirety before running or terminating the wires to ensure proper operation and to avoid damaging equipment. -
Page 6: Preparation For Communication
Example: If the IP address of the switcher is 192.16.1.24, set the computers IP address to 192.168.1.x where x is number between 2 and 254 that is not used by other devices on the network. 6 of 14 SW-0501-HDBT / SW-1001-HDBT Presentation Switcher/Scaler Application Program Interface (API) | 151021-1044... -
Page 7: Accessing The Switcher Via Telnet
Enter user name root and press Enter. When the following screen information appears, connection to switcher is successful. API commands to control the switcher may be entered in the command-line interface. Copyright © 2015 WyreStorm Technologies | wyrestorm.com 7 of 14... -
Page 8: Switcher Commands
Enable/Disable Auto Switching Syntax gbconfig --plug-detect=[Value] Description Enables or disables auto switching. Y: Auto switching enabled Accepted Values: N: Auto switching disabled Example Command: gbconfig --plug-detect=y Response: none 8 of 14 SW-0501-HDBT / SW-1001-HDBT Presentation Switcher/Scaler Application Program Interface (API) | 151021-1044... -
Page 9: Query Auto Switching State (Enabled/Disabled)
--show --line-out=1 --mute Queries that the output of AUDIO OUT port is Description muted or not. Example Command: gbconfig --show --line-out=1 --mute Y: Audio output muted Response: N: Audio output unmuted Copyright © 2015 WyreStorm Technologies | wyrestorm.com 9 of 14... -
Page 10: Configure Video Output Resolution
Makes a CEC-enabled device such as a display device Description connected through HDMI or HDBT port enter standby mode. Example Command: e e_cec_system_standby Response none 10 of 14 SW-0501-HDBT / SW-1001-HDBT Presentation Switcher/Scaler Application Program Interface (API) | 151021-1044... -
Page 11: Rd Party Device Control (Rs-232 2 Port)
The switcher requires a manual reboot (cycle power) after restoring defaults. Example Command: reset_to_default.sh Response: none Reboot the Switcher Syntax reboot Description Reboots the switcher. Example Command: reboot Response: none Copyright © 2015 WyreStorm Technologies | wyrestorm.com 11 of 14... -
Page 12: Publication Disclaimer
WyreStorm reserves the right to change software, control codes and specifications without notice. WyreStorm will not be liable for any use of this information or any changes it may make to those products. The use of this information constitutes an agreement by the user to these limitations and exclusions. - Page 14 Tel: +1 518-289-1293 EMEA: Unit 22, Ergo Business Park, Swindon, Wiltshire, SN3 3JW, UK Tel: +44 (0) 1793 230 343 WyreStorm Technologies reserves the right to change physical appearance or technical specification of this product at any time. Visit wyrestorm.com...
