3.3 mSATA/m.2 Card Installation
1.
Remove the 10 screws on the rear cover.
2.
Remove the 6 screws on the reinforced board.
3.
Insert an mSATA/m.2 card into the slot.
4.
Replace and tighten the screws on the reinforced board.
5.
Replace the rear cover and secure in place with screws.
Figure 3.2 Installing an mSATA/m.2 Card
17
