Summary of Contents for Burkert SE58 S
- Page 1 Typ SE58 S Transmitter Operating Instructions...
- Page 2 SE58 S Ausführliche Informationen finden Sie in der Bedienungsanleitung unter der Internetadresse: country.burkert.com > SE58 oder scannen Sie folgenden QR-Code ein: Detailed information can be found in the operating instructions at the Internet address: country.burkert.com > SE58 scan the following QR code: Vous trouverez des informations détaillées dans le mode d'emploi...
- Page 3 SE58 S INDEX INTRODUCTION SAFETY INFORMATION SAFETY CONVENTION TECHNICAL CHARACTERISTICS TORQUES ELECTRICAL CONNECTIONS GROUNDING POWER SUPPLY OUTPUTS WIRING ACCESS TO THE CONFIGURATION MENU START VISUALIZATION PAGES ON MCP INTERFACE TRANSMITTER ACCESS CODE MANUAL REVIEWS English...
-
Page 4: Safety Information
SE58 S INTRODUCTION • These operating instructions and the description of device functions are provided as part of the scope of supply. • They could be modified without prior notice. The improper use, possible tampering of the device or parts of it and substitutions of any components not original, renders the warranty automatically void. - Page 5 Specialists must take care during installation and use personal protective equipment as provided by any related security plan about risk assessment. • Never mount or wire SE58 S while it is connected to the power supply and avoid any liquid contact with the device’s internal components. •...
-
Page 6: Technical Characteristics
SE58 S TECHNICAL CHARACTERISTICS Electrical Characteristic Device classification: class I, IP67/IP68 installation category II, rated pollution degree 2. Power supply voltage Power Max min10 / max30 V DC min10 / max30 V DC • Voltage variations must not exceed ±10% of the nominal one. - Page 7 SE58 S Data Plate On the data plate there is some technical information Transmitter data Transmitter Transmitter data Type SE 58 S (B0B1A0A) Transmitter model AAZ000004 Transmitter serial number XXXXXX Identification code Power 18-30 V DC 1W Min-Max supply voltage range-supply voltage type-max. power consumption MaxTa 60°C...
- Page 8 SE58 S TORQUES DESCRIPTION TIGHTENING TORQUE Nm POS. SCREW M6x16 PG9 PLUG CABLE GLAND PG11 English...
-
Page 9: Electrical Connections
SE58 S ELECTRICAL CONNECTIONS VERSION WITH CABLE 1 (+) POWER SUPPLY 2 (+) OUTPUT 1 / INPUT 3 (+) OUTPUT 2 (OPTIONAL) 4 (+) 4-20mA max load: 500Ω OUTPUT (OPTIONAL) 5 (-) POWER SUPPLY / OUTPUTS / INPUT 6 SHIELD (CONNECT TO GROUND) -
Page 10: Power Supply
SE58 S GROUNDING ALWAYS ensure that the device is grounded (earthed) correctly. The grounding ensures that the equipment and liquid are equipotential. POWER SUPPLY POWER SUPPLY + POWER SUPPLY - • Before connecting the power supply, verify that the main voltage is within the limits indicated on data plate. -
Page 11: Outputs Wiring
SE58 S OUTPUTS WIRING DIGITAL OUTPUTS • Opto-insulated output • Maximum switching voltage: 30V 2 (Out1) Maximum switching current: 100mA @ 25°C 3 (Out2) • Maximum saturation voltage between collector and emitter @100mA: 1.2V • Maximum switching frequency (load on the collector or emitter, RL=470Ω, VOUT=24V ):... -
Page 12: Access To The Configuration Menu
SE58 S ACCESS TO THE CONFIGURATION MENU You can access the device configuration menu only by MCP. MCP is a software that can be installed on Microsoft Windows® and allows you to set all the functions of the transmitter and customize the menu. To use the MCP interface, see its own manual . - Page 13 SE58 S START VISUALIZATION PAGES ON MCP INTERFACE Electrode 2 resistance Electrode 1 resistance Video term. connected full scale in use (1-2) Flow speed % full scale Flow rate graph Flow rate value Flow rate trend Alarms list page...
- Page 14 SE58 S TRANSMITTER ACCESS CODE The access for the device configuration is regulated by six access levels logically grouped. Every level is protected by a different code. Access Levels 1-2-3-4 Freely configurable by user Access Code Set : Menu 13 System The CODE is inserted by MCP.
- Page 15 SE58 S The following example shows how to change the Full scale by Quick Start menu; the second illustrates how to change the function by the Main menu. EXAMPLE: modifying the full scale value from 4.0 l/s to 5.0 dm3/s, from the “Quick start menu”...
- Page 16 SE58 S EXAMPLE: modifying the full scale value from 4.0 l/s to 5.0 dm3/s, from the “Main Menu” (quick start menu enabled) Press enter key to access in the Use the right-left arrow keys to select the “Quick Start menu”...
- Page 17 SE58 S 4 11 4 12 Press the enter key to confirm the changed value Press the esc key to exit from the “quick start menu” 4 13 1 4 14 Press the esc key to exit from the menu and return...
- Page 18 SE58 S At the end of its lifetime, this product shall be disposed of in full compliance with the environmental regulations of the state in which it is located. English...
- Page 19 SE58 S MANUAL REVIEWS REVIEW DATE DESCRIPTION SE58S_EN_DE_BURKERT_R00_1.02.XXXX 25/02/2021 FIRST EDITION SE58S_QUICK_EN_BU_R01_1.04.XXXX 08/10/2021 Changes to data relating to digital output English...
- Page 20 We reserve the right to make technical changes without notice. Technische Änderungen vorbehalten. Sous réserve de modifications techniques. © Bürkert SAS, 2020...
