  • Page 1 Type SE58 M Transmitter Operating Instructions...
  • Page 2  SE58 M Ausführliche Informationen finden Sie in der Bedienungsanleitung unter der Internetadresse: country.burkert.com > SE58 oder scannen Sie folgenden QR-Code ein: Detailed information can be found in the operating instructions at the Internet address: country.burkert.com > SE58 scan the following QR code: Vous trouverez des informations détaillées dans le mode d'emploi...

  • Page 3: Table Of Contents

     SE58 M INDEX INTRODUCTION SAFETY INFORMATION SAFETY CONVENTION TECHNICAL CHARACTERISTICS TORQUES ELECTRICAL CONNECTION AND GROUNDING INSTRUCTIONS ELECTRICAL CONNECTION TRANSMITTER- SENSOR DIGITAL INPUT ON/OFF OPERATION OUTPUTS WIRING START VISUALIZATION PAGES ACCESS TO THE CONFIGURATION MENU TRANSMITTER ACCESS CODE MANUAL REVIEWS...

  • Page 4: Introduction

     SE58 M INTRODUCTION • These operating instructions and description of device functions are provided as part of the scope of supply. • They could be modified without prior notice. The improper use, possible tampering of the device or parts of it and substitutions of any components not original, renders the warranty automatically void.

  • Page 5: Safety Convention

     SE58 M • The specialists must have read and understood these Operating Instructions and must follow the instructions it contains. The Operating Instructions provide detailed information about the transmitter. If you are unclear on anything in these Operating Instructions, you must call the Bürkert service department.

  • Page 6: Technical Characteristics

    Reinf. Nylon Min* Min* The battery will not be charged outside the below limits: + 60 + 50 T board SE58 M < 0 °C °C T board SE58 M > 50 °C +140 +122 °F If the transmitter is supplied in compact version (transmitter over the sensor), consider the ambient temperatures more restrictive, otherwise refer to the relevant manuals.
  • Page 7  SE58 M Data Plate The device label contain the following information: Type SE58 M (B0A1C2B1A4A0) Transmitter model ANZ000001 Transmitter serial number XXXXXX Identification code Power 44-66 Hz 100-240VAC 5VA Min-Max supply voltage range-supply voltage type-max. power consumption MaxTa 50°C...

  • Page 8: Torques

     SE58 M TORQUES To guarantee the housing’s IP degree the following torques are required: Screws Screws Cable HOUSING Housing Version Terminal block for display Glands USB-B MATERIAL screws (1) Screws Cap (3) cover (2) frame ALUMINIUM 6 Nm 5.5 Nm 3 Nm 0.8 Nm...
  • Page 9  SE58 M Stainless steel housing HOUSING Housing PCB Screws Cable Cap USB-B (5) MATERIAL screws (1) Glands (4) Stainless steel 2.5 Nm 0.8 Nm 4 Nm 2.5 Nm HOUSING English...

  • Page 10: Electrical Connection And Grounding Instructions

     SE58 M ELECTRICAL CONNECTION AND GROUNDING INSTRUCTIONS Always ensure that the transmitter and the sensor are grounded (earthed) correctly. The grounding of the sensor and transmitter must ensure that the device and liquid are equipotential. ORING 4700 L(+) N(-)

  • Page 11: Electrical Connection Transmitter- Sensor

     SE58 M ELECTRICAL CONNECTION TRANSMITTER- SENSOR Sudden movements of the electrodes cable could introduce noise. SH = SHIELD OF CABLE internally connected to ground. ELECTRODES RS485 22 21 20 4-20 OUTPUTS OUTPUT OUT2 (+) 4-20 +24V OUT1 (+) 4-20*...

  • Page 12: Digital Input On/Off Operation

     SE58 M DIGITAL INPUT ON/OFF OPERATION INTERNAL POWER SUPPLY EXTERNAL POWER SUPPLY 10KΩ 15(+) 10KΩ 10KΩ 3-40Vdc (ON) 0/1.5Vdc (OFF) 16(+) RESET TOTALIZERS Necessary conditions for enabling the function Block • POS. 6.1 (T+; total positive set on) 3-40V Reset •...

  • Page 13: Outputs Wiring

     SE58 M OUTPUTS WIRING Digital outputs • Opto-insulated output with floating collector and emitter terminals freely connectable 18 OUT 1(+) • Maximum switching voltage: 30V 19 OUT 2(+) • Maximum switching current: 100mA @ 25°C • Maximum saturation voltage between collector and emitter @100mA: 1.2V...

  • Page 14: Start Visualization Pages

     SE58 M START VISUALIZATION PAGES The direct exposure of the transmitter to the solar rays, could damage the liquid crystal display. The visualization pages can be changed according to device’s setup. Push to change visualization Flow rate direction +/-...
  • Page 15  SE58 M Push to change visualization Totalizer Total + Totalizer Partial + Totalizer Total - Totalizer Partial - Electrodes Voltage Electrodes Resistance n°Alarm Alarm List Date and Time Direct Total Totalizer Direct Partial Totalizer Reverse Total Totalizer Reverse Partial Totalizer...

  • Page 16: Access To The Configuration Menu

     SE58 M ACCESS TO THE CONFIGURATION MENU The configuration can be done in two different ways: • By keypad of transmitter • By MCP interface (Virtual display of device) Access Via Keypad SHORT PRESSING (< 1 SECOND): SHORT PRESSING (< 1 SECOND): SHORT PRESSING (<...
  • Page 17  SE58 M Access Via Mcp interface (Virtual Display) MCP is a Windows® software that allows to set all the transmitter functions and personalize the menu. The MCP program is required for the blind version of the transmitter. To use MCP interface consult the relevant user manual.

  • Page 18: Transmitter Access Code

     SE58 M TRANSMITTER ACCESS CODE The access for programming the device is regulated by six access levels logically grouped. Every level is protected by a different code. • Access Level 1-2-3-4 Freely programmable by user Access Code Set : Menu 13 System The CODE is Settable by keyboard or MCP interface.
  • Page 19  SE58 M The following example shows how to change the Fullscale by Quick Start menu; the second illustrates how to change the function by the Main menu. EXAMPLE: modifying the full scale value from 4dm³/s to 5dm³/s, from the “Quick start menu”...
  • Page 20  SE58 M EXAMPLE: modifying the full scale value from 4dm³/s to 5dm³/s, from the “Main Menu” (quick start menu enabled) Press arrow keys to select the Press the ENTER button to cell in which to insert the number access the Quick Start menu of the access code.
  • Page 21  SE58 M At the end of its lifetime, this product shall be disposed of in full compliance with the environmental regulations of the state in which it is located. English...
  • Page 22  SE58 M English...

  • Page 23: Manual Reviews

     SE58 M MANUAL REVIEWS REVIEW DATE DESCRIPTION SE58M_EN_DE_BU_R00_1.02.XXXX 23/03/2021 FIRST EDITION Update for electrical safety certification. SE58M_EN_BURKERT_R01_1.04.XXXX 18/08/2021 Firmware update. SE58M_EN_BURKERT_R02_1.04.XXXX 08/10/2021 Changes to data relating to digital output English...
  • Page 24 We reserve the right to make technical changes without notice. Technische Änderungen vorbehalten. Sous réserve de modifications techniques. © Bürkert SAS, 2020...
