Hypertherm Powermax65 SYNC Reference Manual page 34

Serial Communication Programmer Reference Guide
Fault Code Fault Code
(hex) (decimal)
01F6 502
01F7 503
01FE 510
0208 520
0258 600
0259 601
025A 602
0262 610
03D4 980
03D5 981
03D6 982
Internal component faults
03E8 1000
04B0 1200
0514 1300
07D0 2000
07DA 2010
34
Description
(Fault code 0-50-2)
The torch-lock switch is set to the green "ready to
fire" ( ) position, but the torch is not prepared to fire.
(Fault code 0-50-3)
The system is reading data from the cartridge.
(Fault code 0-51-0)
The plasma power supply was receiving a signal to
start cutting at the same time that the power switch
was set to ON (I). This is sometimes referred to as a
"stuck start."
(Fault code 0-52-0)
The torch is not connected.
(Fault code 0-60-0)
An AC input voltage phase loss occurred.
(Fault code 0-60-1)
The AC input voltage is too low.
(Fault code 0-60-2)
The AC input voltage is too high.
(Fault code 0-61-0)
The AC input is not stable.
(Fault code 0-98-0)
An internal communication failure occurred between
the LCD/control PCB and the DSP PCB.
(Fault code 0-98-1)
A radio frequency (RF) communication failure occurred
between the cartridge and the torch.
(Fault code 0-98-2)
A communication failure occurred between the torch
and the plasma power supply.
(Fault code 1-00-0)
A digital-signal processor (DSP) PCB fault occurred.
(Fault code 1-20-0)
An input/output (I/O) fault occurred.
(Fault code 1-30-0)
A flash memory fault occurred.
(Fault code 2-00-0)
The analog-to-digital converter (ADC) value is out of
range.
(Fault code 2-01-0)
The auxiliary switch is disconnected.
810400 Reference Guide
Steps Required to
Remove?
Yes
No
Yes
Yes
Yes
Yes
Yes
Yes
No, but recommended
No, but recommended
No, but recommended
Yes
Yes
Yes
Yes
Yes
Powermax65/85/105 SYNC
