ASM Zip-Spray 3400G Operation

Airless gas sprayer
Hide thumbs
Table of Contents

Advertisement

Quick Links

Download this manual
Operation
3400G Airless Gas
Sprayer
-For the application of architectural paints and coatings-
Model 249616
3000 psi (20.7 MPa, 207 bar) Maximum Working Pressure
Important Safety Instructions
Read all warnings and instructions in this manual.
Save these instructions.
Related
Manuals
Repair
311207
Pump
311061
Gun
309971
311206A

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the Zip-Spray 3400G and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Related Manuals for ASM Zip-Spray 3400G

Summary of Contents for ASM Zip-Spray 3400G

  • Page 1 Operation 3400G Airless Gas Sprayer 311206A -For the application of architectural paints and coatings- Model 249616 3000 psi (20.7 MPa, 207 bar) Maximum Working Pressure Important Safety Instructions Read all warnings and instructions in this manual. Save these instructions. Related Manuals Repair 311207...
  • Page 2 Warnings Warnings The following are general warnings are related to the setup, use, grounding, maintenance and repair of this equip- ment. Additional more specific warnings may be found throughout the body of this manual where applicable. Symbols appearing in the body of the manual refer to these general warnings. When these symbols appear throughout the manual, refer back to these pages for a description of the specific hazard.

  • Page 3: Specifications

    Read fluid and solvent manufacturer’s warnings. For complete information about your material, request MSDS from distributor or retailer. • Check equipment daily. Repair or replace worn or damaged parts immediately with genuine ASM replacement parts only. • Do not alter or modify equipment.
  • Page 4 Controls Controls 311206A...

  • Page 5: Installation

    Installation Installation Grounding and Electric WARNING Requirements HOT SURFACE HAZARD! Engine and drive housing may be very hot during The sprayer must be grounded. Grounding reduces the operation and could burn skin if touched. risk of static by providing an escape wire for the electri- cal current due to static build up.

  • Page 6: Tip Selection

    Tip Selection Tip Selection Selecting Tip Hole Size Tips come in a variety of hole sizes for spraying a range of fluids. Your Zip Spray sprayer includes the tip most likely to satisfy common spraying applications. Use the tables below to determine the range of recommended tip hole sizes for each fluid type.

  • Page 7: Operation

    Operation Operation Pressure Relief Procedure 1. Engage trigger lock. 2. Turn pump switch OFF. Setup 1. Connect high-pressure hose to sprayer. Tighten 3. Turn engine OFF. securely. 4. Disengage trigger lock. 2. Connect other end of hose to gun. 5. Turn pressure to lowest setting. Trigger gun to relieve pressure.
  • Page 8 2. Turn prime valve down. turn pressure control to low- est pressure. 4. Remove tip guard. 3. Set pump switch OFF. 4. Fill throat packing nut with ASM Packing Seal fluid. 5. Check engine oil level. Add SAE 10W-30 (summer) or 5W-20 (winter), if necessary. 5. Start Engine.
  • Page 9 Operation b. Move choke to Closed. c. Set throttle to Fast. 7. Increase pressure enough to start pump stroking and allow fluid to circulate for 15 seconds; turn prime valve horizontal. d. Set engine switch ON. 8. Take spray gun trigger safety OFF. e.

  • Page 10: Switch Tip And Guard Assembly

    Operation Note: Inspect fittings for leaks. Do not stop leaks with your hand or a rag! If leaks occur, turn sprayer OFF immediately. Follow Pressure Relief Procedure, page 6. Tighten leaky fittings. Repeat Startup, steps 1-8. If no leaks, continue to trigger gun until system is thoroughly flushed.

  • Page 11: Clearing Tip Clogs

    Operation Clearing Tip Clogs 2. Put trigger safety ON, return SwitchTip to original position, take trigger safety OFF and continue 1. Release trigger, put safety ON. Rotate SwitchTip. spraying. Take trigger safety OFF and trigger gun to clear the clog. Never point gun towards your hand or into a rag! 311206A...
  • Page 12 Cleanup Cleanup 5. Clean all parts in flushing fluid. Use a soft-bristle brush to remove dried-on material. 1. Relieve Pressure 2. Turn prime valve down. 6. Remove siphon tube set from paint and place in flushing fluid. Use water for water base paint and 3.
  • Page 13 20 seconds to clean drain tube. 12. Raise siphon tube above flushing fluid and run sprayer for 15 to 30 seconds to drain fluid. Turn pump switch OFF. Turn engine OFF. 16. Store sprayer with mineral spirits or ASM Pump Life fluid. 311206A...
  • Page 14 Notes Notes 311206A...

  • Page 15: Technical Data

    Technical Data Technical Data Honda Engine Inlet paint strainer ....16 mesh (1190 micron) Power Rating @ 3700 rpm stainless steel screen, reusable ANSI ........4.0 Horsepower DIN 6270B/DIN 6271 NA ..........2.1 Kw - 2.8 Ps NB ..........2.6 Kw - 3.6 Ps Maximum working pressure ...3000 psi (21 MPa, 210 bar) Outlet paint filter ....60 mesh (250 micron) stainless steel screen, reusable Noise Level...

  • Page 16: Asm Standard Warranty

    ASM distributor to the original purchaser for use. With the exception of any special, extended, or limited warranty published by ASM, ASM will, for a period of twelve months from the date of sale, repair or replace any part of the equipment determined by ASM to be defective.
