ASM Zip-Spray 2300 Plus 240V Manual

Electric airless sprayers
Hide thumbs Also See for Zip-Spray 2300 Plus 240V:

Advertisement

Quick Links

Download this manual
Operation / 작동 / 操作
Electric Airless Sprayers
전기식 에어리스 도장기
电动无气喷涂机
- For portable spray applications of architectural paints and coatings -
- 适用于建筑涂料和涂层的便携喷涂应用 -
- 구조적 도장 및 코팅에 대한 휴대용 스프레이 분야 -
3300 psi (227 bar, 22.7 MPa) Maximum Working Pressure /
Important Safety Instructions / 重要安全说明 / 중요 안전 정보
Read all warnings and instructions in this manual. Save these instructions.
请阅读本手册的所有警告及说明。妥善保存这些说明。
이 설명서의 모든 경고와 지침을 읽고 , 이러한 지침을 보관해 두십시오 .
Related Manuals
312496
312363 (English)
312364 (French)
312365 (Spanish)
312362
Australian Patent 2004313479
最大工作压力
최대 허용 압력
/
™
ASM Zip-Spray
2300 Plus 240V: 247533
ASM M2300 Plus 110V: 247534
ASM M2300 Plus 240V: 247535
312490B
EN ZH KO
ti10702a

Advertisement

loading
Need help?

Need help?

Do you have a question about the Zip-Spray 2300 Plus 240V and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Related Manuals for ASM Zip-Spray 2300 Plus 240V

Summary of Contents for ASM Zip-Spray 2300 Plus 240V

  • Page 1 이 설명서의 모든 경고와 지침을 읽고 , 이러한 지침을 보관해 두십시오 . Related Manuals 312496 312363 (English) 312364 (French) 312365 (Spanish) 312362 Australian Patent 2004313479 ti10702a ™ ASM Zip-Spray 2300 Plus 240V: 247533 ASM M2300 Plus 110V: 247534 ASM M2300 Plus 240V: 247535...

  • Page 2: Fire And Explosion Hazard

    Warnings Warnings The following are general warnings related to the setup, use, grounding, maintenance and repair of this equipment. Additional, more sepcific warnings may be found throughout the body of this manual where applicable. Symbols appearing in the body of the manual refer to these general warnings. When these symbols appear throughout the manual, refer back to these pages for a description of the specific hazard.

  • Page 3: Personal Protective Equipment

    Read fluid and solvent manufacturer’s warnings. For complete information about your material, request MSDS from distributor or retailer. • Check equipment daily. Repair or replace worn or damaged parts immediately with genuine ASM replacement parts only. • Do not alter or modify equipment.
  • Page 4 警告 警告 以下为与本设备的设置、使用、接地、维护及修理有关的一般性警告。此外，在本手册的其它适当地方还有更明确的 警告。本手册各处出现的标志系指这些一般性警告。当本手册的某处出现这些标志时，请回到以下各页以了解对具体 危险的说明。 警告 火灾和爆炸危险 工作区内的溶剂及涂料烟雾等易燃烟雾会点燃或爆炸。为避免火灾及爆炸： 仅在通风良好的地方使用此设备。 • 清除所有火源，如引火火焰、烟头、手提电灯及塑胶遮蔽布 （可产生静电火花） 。 • 喷涂机会产生电火花。当喷涂机使用易燃液体或在其附近使用易燃液体或用易燃液体进行冲洗或清洗 • 时，要让喷涂机离开爆炸性蒸气至少 20 英尺 （6 m） 。 保持工作区清洁，无溶剂、碎片、汽油等杂物。 • 存在易燃烟雾时不要插拔电源插头及开关电灯。 • 将工作区内的设备及导电物体接地。请阅读接地说明。 • 如果出现静电火花或感到有电击，要立刻停止操作。在找出并纠正问题之前，不要使用设备。 • 工作区内要始终备有灭火器。 • 电击危险 系统接地不当、设置不正确或使用不当都可导致电击。 进行设备维修之前，要关闭电源并切断电源线的连接。 • 只能使用已接地的电源插座。 • 只能使用三芯加长电线。 • 确保喷涂机及加长电线上的接地插脚完好无损。...
  • Page 5 警告 警告 设备误用危险 误用设备会导致严重的人员伤亡。 不要超过额定值最低的系统部件的最大工作压力或温度额定值。请阅读所有设备手册中的技术数据。 • 请使用与设备的流体部件相适应的流体或溶剂。请阅读所有设备手册中的技术数据。 阅读流体及溶 • 剂生产厂家的警告。有关涂料的完整资料，请向涂料分销商或零售商索要材料安全数据表 （MSDS） 。 要每天检查设备。已磨损或损坏的零部件要立刻修理或更换，只能使用 ASM 的原装替换用零部件进 • 行修理或更换。 不要对设备进行改动或修改。 • 只能将设备用于其特定的用途。有关资料请与 ASM 公司的经销商联系。 • 让软管和电缆远离公共区域、尖锐边缘、移动部件及热的表面。 • 不要扭绞或过度弯曲软管或用软管拽拉设备。 • 要遵照所有适用的安全规定进行。 • 儿童和动物要远离工作区。 • 疲劳时或在吸毒或酗酒之后不得使用此设备。 • 高压铝质部件危险 不要在加压的铝质装置中使用 1,1,1- 三氯乙烷、二氯甲烷、其它卤代烃溶剂或含有这些溶剂的流体。否 则会导致剧烈的化学反应和设备破裂，并可造成严重的人员伤亡及财产损失。 流体或烟雾中毒危险 如果吸入有毒的烟雾、食入有毒的流体或让它们溅到眼睛里或皮肤上，都会导致严重伤害或死亡。...
  • Page 6 경고 경고 다음은 이 장비의 설정 , 사용 , 접지 , 유지보수 및 수리에 관한 일반적인 경고입니다 . 더 구체적인 경고가 이 설명서의 관련 부분에 추가로 제공될 수 있습니다 . 설명서 본문에 나타나는 기호는 이러한 일반 경고를 의미합 니다 . 설명서를 읽는 도중 이러한 기호를 만나면 이 페이지로 돌아와서 관련 위험에 대한 설명을 참조하십시오 . 경고...
  • Page 7 서의 기술 자료를 읽고 , 유체 및 솔벤트 제조업체의 경고를 읽으십시오 . 재료에 대한 전체 정 보가 필요하면 유통업체 또는 대리점에게 MSDS 를 요청하십시오 . 장비는 매일 점검하십시오 . 마모되었거나 손상된 부품이 있으면 즉시 수리하거나 정품 ASM 부품 • 으로 교체하십시오 .
  • Page 8 部件辨认 구성품 식별 Component Identification / Component Identification / 部件辨认 / 구성품 식별 / ti10703a English 中文 한국어 Pressure Control 压力控制器 압력 제어기 ON/OFF switch ON/OFF 开关 온 / 오프 스위치 Pressure Guage (not on all models) 压力表 （并非所有型号都有） 압력 게이지 ( 일부 모델에는 없음 ) Power Cord 电源线...
  • Page 9 部件辨认 구성품 식별 Component Identification / Grounding / 接地 / 접지 English 中文 한국어 The sprayer must be 必须将喷涂机接地。 도장기는 반드시 접 grounded. Grounding 通过接地，可给电流 지해야 합니다 . 접지 reduces the risk of 提供静电聚集时或发 를 하면 정전기 축적 static and electric 生短路时逃逸的通路，...
  • Page 10 部件辨认 구성품 식별 Component Identification / Ground 120 volt plug ti4297a ti4295 Power Requirements Extension Cords • Do not modify plug! If it will not fit • 100-120V units require • Use an extension cord with an • If an extension cord is necessary, in outlet, have grounded outlet 100-120 VAC, 50/60 Hz, 15A, undamaged ground contact.
  • Page 11 部件辨认 구성품 식별 Component Identification / ti5851a ti5850a Pails • Solvent and oil/based fluids: • Do not place pail on a nonconduc- • Grounding a metal pail: connect a • To maintain grounding conti- follow local code. Use only con- tive surface such as paper or card- ground wire to the pail by clamping nuity when flushing or relieving...

  • Page 12: Pressure Relief Procedure / 泄压步骤

    泄压步骤 압력 해제 절차 Pressure Relief Procedure / Pressure Relief Procedure / 泄压步骤 / 압력 해제 절차 English 中文 한국어 To reduce risk of 为减少由于注射造成 부상의 위험이 있으 injury from injection, 人员受伤的危险，无 므로 압력 해제 , 스 follow this procedure 论何时只要是要求您...
  • Page 13 本说明书各处所显示的插图均为 233960 型设备。您的喷涂机型号在外观上可能会与图中所示略微不同。 지침의 모든 그림에는 모델 233960 이 사용되었습니다 . 따라서 귀하의 도장기 모델은 그림과 약간 다를 수 있 습니다 . Connect ASM airless Connect other end of Tighten securely. Remove tip guard. hose to sprayer. Tighten hose to gun.
  • Page 14 Check inlet strainer for Fill throat packing nut Turn power OFF. Plug power supply cord clogs and debris. with ASM Packing Seal to into a properly grounded prevent premature electrical outlet. packing wear. Do this each time you spray.
  • Page 15 设置 설치 Setup / ti2719a Turn prime valve down. 10 Place siphon tube set in grounded metal pail partially filled with flushing fluid. Attach ground wire to pail and to true earth ground. Do 1. - 5. of Startup, page 16 to flush out storage oil shipped in sprayer.
  • Page 16 起动 작동 시작 Startup / Startup / 起动 / 작동 시작 ti2712a ti2706a Turn pressure control to Turn power ON. Increase pressure to start Turn prime valve lowest pressure. motor and allow fluid horizontal.Take spray gun to circulate through drain trigger safety OFF.
  • Page 17 起动 작동 시작 Startup / ti2714a PAINT Hold gun against grounded Inspect for leaks. Do not stop Place siphon tube in paint Trigger gun again into metal flushing pail. Trigger leaks with hand or a rag! If pail. flushing pail until paint gun and increase fluid leaks occur, do Pressure appears.
  • Page 18 起动 작동 시작 Startup / ti10313a ti10314a Move gun to paint pail and 10 Screw tip assembly onto trigger for 20 seconds. Set gun. Tighten. For gun gun safety ON. assembly instructions, see gun manual, 312363, 312364, 312365. 将喷枪移向涂料桶并扣动 10 将喷嘴组件旋到喷枪上。 扳机...
  • Page 19 起动 작동 시작 Startup / Spraying / 喷涂 / 스프레이 작업 heavy edges ti2758a ti2757a Spray test pattern. Start with pressure turned to its lowest Hold gun perpendicular, 10-12 in. from surface. Spray back setting, then gradually increase pressure gradually until and forth, overlapping by 50%.
  • Page 20 起动 작동 시작 Startup / Clearing Clog / 清除堵塞物 / 막힌 곳 뜷기 a.) Release trigger, put safety ON. a.) Put safety ON. b.) Rotate SwitchTip. b.) Return Switch to original position. c.) Take safety OFF. c.) Take safety OFF and continue spraying. d.) Trigger gun to clear clog.
  • Page 21 清洗 청소 Cleanup / Cleanup / 清洗 / 청소 ti2707a WASTE RESÍDUOS À JETER ti2614a DESECHO ti2718a ti2595a Turn power OFF and Turn pressure to lowest Put drain tube in pail. Remove guard and unplug sprayer. setting. Trigger gun to Turn prime valve down.
  • Page 22 清洗 청소 Cleanup / ti2810a ti2712a ti2817a ti2707a Remove siphon tube set from Plug in sprayer. Turn power Hold gun against paint pail. Move gun to flushing pail, paint and place in flushing ON. Turn prime valve Take trigger safety OFF. hold gun against pail, trigger fluid.
  • Page 23 清洗 청소 Cleanup / ti2719a ti2719a ti2712a PAINT ti2820a FLUSH ti2707a Turn prime valve down and Raise siphon tube above Close drain valve. Trigger Open prime valve. allow flushing fluid to flushing fluid and run sprayer gun into flushing pail to purge circulate for 1 to 2 minutes for 15 to 30 seconds to drain fluid from hose.
  • Page 24 清洗 청소 Cleanup / ti2776a ti2814a Pump Armor 13 If you have a filter 13 Remove filter from gun if 14 If flushing with water, 15 Wipe sprayer, hose and installed on your installed. Clean and flush again with mineral gun with a rag soaked in sprayer, remove filter.

  • Page 25: Technical Data

    Technical Data Technical Data Power requirements ........100/120V AC, 50/60 hz, 11A, 1 phase 240V AC, 50/60 hz, 7.0 A, 1 phase Generator required.
  • Page 26 기술 자료 기술 자료 전기 사양 ..... . . 100/120V AC, 50/60 hz, 11A, 단상 240V AC, 50/60 hz, 7.0 A, 단상 필요한...
  • Page 27 참고 注释 Notes / Notes / 참고 / 注释 312490B...
  • Page 28 With the exception of any special, extended, or limited warranty published by ASM, ASM will, for a period of twelve months from the date of sale, repair or replace any part of the equipment determined by ASM to be defective.

This manual is also suitable for:

Zip-spray m2300 plus 110vZip-spray m2300 plus 240v247533247534247535
