Flight Model F172 Silence Twister 50CC Assembly Manual

Hide thumbs

Advertisement

Quick Links

Download this manual
Wing Span:95in/2413mm;
Wing Area:90.3sq.dm;
Length:74.8in/1900mm;
CAUTION : this plane is not a toy and should be kept away
children under 16 years of age! Before use , please carefully read
this manual.
●First-time builders should seek advice from people having building
experience in order to assemble the model correctly and to produce its
performance to full extent .
●Assemble this kit only in places out of children's reach!
●Take enough safety percautions prior to operating this model.
You are responsible for this model's assembly and safe operation!
●Always keep this instruction manual ready at hand for quick
reference,even after completing the assembly.
Flying Weight:7000-7500g;
Radio:9Channel 9-10Servos;
Engine:50CC Gas
P.1

Advertisement

loading
Need help?

Need help?

Do you have a question about the F172 Silence Twister 50CC and is the answer not in the manual?

Questions and answers

Related Manuals for Flight Model F172 Silence Twister 50CC

Summary of Contents for Flight Model F172 Silence Twister 50CC

  • Page 1 Wing Span:95in/2413mm; Flying Weight:7000-7500g; Wing Area:90.3sq.dm; Radio:9Channel 9-10Servos; Length:74.8in/1900mm; Engine:50CC Gas CAUTION : this plane is not a toy and should be kept away children under 16 years of age! Before use , please carefully read this manual. ●First-time builders should seek advice from people having building experience in order to assemble the model correctly and to produce its performance to full extent .
  • Page 2 MAIN WING Connect the aileron and the main wing by hinges. Be sure to apply instant type glue to both sides of each hinges. Install the aileron horns in place with AB glue Align the holes in the horns Cut the servo holes on the bottom of the main wings...
  • Page 3 Put the servo into the hole and fix it with screws. Link the servo arms and tri-horns with pushrod Connect the main wings and the fuselage with joiner. Push rods Rudder servo arm...

  • Page 4: Stabilizer And Elevator

    Finished photo for the main wing installation STABILIZER AND ELEVATOR Fix up the stabilizer and rudder with hinges and AB glue. Connect the rudder to the fuselage the horns into the original design hole location by hinges and AB glue.
  • Page 5 Cut the servo holes on the profile of the fuselage Install the servo in the servo-tray as shown Screw the servo to the fuselage. Be assured that the screw is fixed up.
  • Page 6 Link the elevator servo to the elevator with pushrod. Check to make sure you have the servos so fuselage with work properly As shown in picture, This is finished for the servo. ABBolt on tabs...
  • Page 7 Attach an metal threaded RC link to each threaded coupler. Attach the RC links to attach the servo arm to the ruddert servo as shown Adjust rudder pull-pull cables to desied tension by screwing in or out on the threaded couplers and or ball links.Make all adjustments with the rudder servos Push...

  • Page 8: Main Landing Gear

    Use screws to fix up the tail wheel on the tail of the fuselage. Plasti Finished photo as shown. MAIN LANDING GEAR Fix up the landing gear on the fuselage bottom with 4 screws. ● Bottom View...
  • Page 9 Install the wheel as shown. Install the wheel cover, and fix it up to landing gear with screw. The finished photo as shown.
  • Page 10 ENGINE Drill the engine mounting holes as the board provided Install the engine mount on both sides with four screws Use the ruler to measure the length from firewall to airscrew P.10...
  • Page 11 Install the propeller and spinner as shown Draw the engine ecnter line and thrust line darker with a ball point Note the 2 degree right thrust built in to the firewall. The cowl is already built with this offset as well. going to use a DA 50 or measure your engines mounting location.
  • Page 12 Install the fuel tank mounting ties under the fuel tank floor. Install the battery,receiver and switch in place as shown. CANOPY AND COWL Velcro tank Install the canopy into the fuselage as shown P.12...
  • Page 13 Mount the cowl using the cowl mounting screws and rubber backed washers. CG POSITION & CONTROL THROWS 6.14in P.13...
  • Page 14 THE FINISHED PHOTO Another scheme for choice Dong Guang Flight Model CO.,Ltd ADD:No.10,Fu Ning Street,Xian Xi Industrial,Chang An Town,Dong Guan City,Guang Dong Province,China Tel: +86-769-85070618 / +86-769-89790965 Fax: +86-769-85091868 E-mail:info@flight-model.com P.14...
  • Page 15 Web: http://www.flight-model.com/product/eindex.asp http://flight-model.preview.alibaba.com/ P.15...
