DEMO MANUAL SCP-LT8362-S-EVALZ
MODE PIN CONFIGURATION
The SCP-LT8362-B-EVALZ is configured by default for
Burst Mode at light loads for efficiency. The MODE pin can
also be configured to burst with spread spectrum, if de-
sired. The table below shows the various configurations
possible with the MODE pin.
Table 4. Settings for MODE Pin Configuration
MODE
Burst Mode
Burst/Spread Spectrum
Pulse Skip
Pulse Skip/Spread Spectrum
Clock Sync/Pulse Skip
If the clock synchronization option is desired, the SCP-
LT8362-B-EVALZ can be driven from an external source
via the optional SMA connector J1.
4
R2
R4
R12
0W
Open
Open
100k
Open
Open
Open
Open
Open
Open
Open
0W
Open
0W
Open
