ASROCK Rack EP2C612D16-2L2T Quick Installation Manual

*15G065018100AK*
P/N: 15G065018100AK V1.0
Quick Installation Guide
EP2C612D16-2L2T / EP2C612D16-4L
The server board User's Manual is available for download from the ASRock Rack's official website
at http://www.asrockrack.com.
Take note of the following precautions before you install server board components or change any
server board settings.
1. Unplug the power cord from the wall socket before touching any components.
2. To avoid damaging the server board's components due to static electricity, NEVER place your
server board directly on the carpet or the like. Also remember to use a grounded wrist strap or
touch a safety grounded object before you handle the components.
3. Hold components by the edges and do not touch the ICs.
4. Whenever you uninstall any component, place it on a grounded anti-static pad or in the bag
that comes with the component.
5. When placing screws into the screw holes to secure the server board to the chassis, please do
not over-tighten the screws! Doing so may damage the server board.
2 Motherboard Layout
1 2
DDR4_G1 (64 bit, 288-pin module, Blue)
DDR4_G2 (64 bit, 288-pin module,
DDR4_H1 (64 bit, 288-pin module, Blue)
DDR4_H2 (64 bit, 288-pin module,
60
59
USB 3.0
T: USB1
B: USB2
REAR_FAN1
58
CPU2_FAN2
REAR_FAN2
DDR4_F2 (64 bit, 288-pin module, White)
57
DDR4_F1 (64 bit, 288-pin module, Blue)
DDR4_E2 (64 bit, 288-pin module, White)
DDR4_E1 (64 bit, 288-pin module, Blue)
1
T B1
56
EP2C612D16-4L
55
PCIE6
Super
I/O
PCIE5
(White)
PCIE4
PCIE3
(Blue)
PCIE2
PCIE1
(White)
PMBUS_SEL_DAT1
PMBUS_SEL_CLK1
CHASSIS_ID2
PMBUS_SEL_ALT1
FRONT_LAN_3_4 CHASSIS_ID0
CHASSIS_ID1
PCIE_PWR1 1
1
BIOS
BMC 1 1
1
NCSI_SEL1
ROM 64Mb
1
1 1
53 52 51 50 49 48 47 46
54
3 I/O Panel
1 3 5
2 4 6
No. Description No. Description
1 Serial Port (COM1) 5 LAN RJ-45 Port (IPMI_LAN)
2 VGA Port (VGA1) 6 USB 3.0 Ports (USB3_1_2)
EP2C612D16-2L2T:
3 GLAN RJ-45 Port (LAN2) 7
EP2C612D16-4L:
EP2C612D16-2L2T:
4 GLAN RJ-45 Port (LAN1) 8
EP2C612D16-4L:
All manuals and user guides at all-guides.com
4
3
33.0cm (13.0 in)
IPMB_1
1
1
White )
ATX12V3
White )
CPU2
(Blue)
(Blue) RoHS
BATTERY1
(White)
BMC_SMB_2
BMC_SMB_1
USB3_3_4
NMI_BTN1 PANEL1
AUX_PANEL1
PLED PWRBTN
1
1
1 1 1
1
HDLED RESET
PECI1 TPM1
45 44 43 42 41 40 39 38
4 Jumper Cap On/Off
7 8
10G LAN RJ-45 Port (LAN3)
GLAN RJ-45 Port (LAN3)
10G LAN RJ-45 Port (LAN4)
GLAN RJ-45 Port (LAN4)
1 Install the Server Board
1
Insert the server board into the chassis.
2
A f f i x t he screws clock w ise into t he
mounting holes in all of the corners of
the server board.
Do not over-tighten the screws
5 6 7
ATXPWR1
PSU_SMB1
FRNT_FAN2
FRNT_FAN1
ATX12V2
DDR4_A1 (64 bit, 288-pin module, Blue )
DDR4_A2 (64 bit, 288-pin module, White)
DDR4_B1 (64 bit, 288-pin module, Blue)
DDR4_B2 (64 bit, 288-pin module, White )
CPU1_FAN1
CPU1
DDR4_D2 (64 bit, 288-pin module, White )
DDR4_D1 (64 bit, 288-pin module, Blue)
DDR4_C2 (64 bit, 288-pin module, White )
DDR4_C1 (64 bit, 288-pin module, Blue)
FRNT_FAN3
Intel
C612 SATA_SGPIO1
1
1
SATA_SGPIO2
1
SSATA_SGPIO1
USB3_5
SPEAKER1
1 1
USB_1_2 M_SATA_0
ME_RECOVERY1 SSATA_2
FRNT_FAN4
1
1
M_SATA_1 SSATA_3
37 36 35 34 33 32 31 30
When the jumper cap is placed on the pins, the
jumper is "Short". If no jumper cap is placed on the
pins, the jumper is "Open".
The illustration shows a 3-pin jumper whose pin1
and pin2 are "Short" when a jumper cap is placed on
these 2 pins.
www.asrockrack.com
2 x 288-pin DDR4 DIMM Slots
1
(DDR4_G2, DDR4_H2, White)
2 2 x 288-pin DDR4 DIMM Slots (DDR4_G1, DDR4_H1, Blue)
3 LGA 2011-3 CPU Socket (CPU2)
4 Intelligent Platform Management Bus header (IPMB_1)
5 ATX 12V Power Connector (ATX12V3)
8
6 PSU SMBus (PSU_SMB1)
9
7 ATX Power Connector (ATXPWR1)
10
8 Front Fan Connector (FRNT_FAN2)
9 Front Fan Connector (FRNT_FAN1)
10 ATX 12V Power Connector (ATX12V2)
11
11 2 x 288-pin DDR4 DIMM Slots (DDR4_A1, DDR4_B1, Blue)
12 2 x 288-pin DDR4 DIMM Slots
12
(DDR4_A2, DDR4_B2, White)
13 CPU1 Fan Connector (CPU1_FAN1)
13
14 LGA 2011-3 CPU Socket (CPU1)
2 x 288-pin DDR4 DIMM Slots (DDR4_C2, DDR4_D2,
15
White)
14
16 2 x 288-pin DDR4 DIMM Slots (DDR4_C1, DDR4_D1, Blue)
17 Front Fan Connector (FRNT_FAN3)
18 SATA SGPIO Connector (SATA_SGPIO1)
19 SATA SGPIO Connector (SATA_SGPIO2)
20 SATA3 Connector (SATA_1), White
21 SATA3 Connector (SATA_0), White
15
22 SATA3 Connector (SATA_3), White
23 SATA3 Connector (SATA_2), White
16
24 SATA3 Connector (SATA_5), White
17
25 SATA3 Connector (SATA_4), White
18
19
26 SATA3 Connector (SSATA_1), White
20
21
27 SATA3 Connector (SSATA_0), White
28 SSATA SGPIO Connector (SSATA_SGPIO1)
22
23
29 Front Fan Connector (FRNT_FAN4)
30 SATA3 Connector (SSATA_2), White
24
25
31 SATA3 Connector (SSATA_3), White
32 SATA3 Connector (M_SATA_0), White
26
27
33 SATA3 Connector (M_SATA_1), White
34 ME Recovery Jumper (ME_RECOVERY1)
28
35 Speaker Header (SPEAKER1)
29
36 USB 2.0 Header (USB_1_2)
37 Vertical Type A USB 3.0 (USB3_5)
38 USB 3.0 Header (USB3_3_4)
39 System Panel Header (PANEL1)
40 Auxiliary Panel Header (AUX_PANEL1)
41 BMC SMBus Header (BMC_SMB_1)
42 TPM Header (TPM1)
43 BMC SMBus Header (BMC_SMB_2)
44 CPU PECI Mode Jumper (PECI1)
45 Non Maskable Interrupt Button (NMI_BTN1)
46 Chassis ID1 Jumper (Chassis ID1)
47 Chassis ID0 Jumper (Chassis ID0)
48 Front Lan LED Connector (FRONT_LAN_3_4)
49 Chassis ID2 Jumper (Chassis ID2)
50 NCSI Mode Jumper (NCSI_SEL1)
51 PMBUS Mode Jumper (PMBUS_SEL_ALT1)
52 PMBUS Mode Jumper (PMBUS_SEL_CLK1)
53 PMBUS Mode Jumper (PMBUS_SEL_DAT1)
54 PCIE Power Connector (PCIE_PWR1)
55 Thunderbolt Connector (TB1)
56 2 x 288-pin DDR4 DIMM Slots (DDR4_E1, DDR4_F1, Blue)
2 x 288-pin DDR4 DIMM Slots (DDR4_E2, DDR4_F2,
57
White)
58 Rear Fan Connector (REAR_FAN2)
59 Rear Fan Connector (REAR_FAN1)
60 CPU 2 Fan Connector (CPU2_FAN2)
