- Page 1 CLUB SERIES TRICEP ASSEMBLY INSTRUCTIONS Part # 7167101 Revision:10/12/01 Rev D...
- Page 2 PARTS LIST PART # DESCRIPTION PART # DESCRIPTION 69928xx TOWER 3202404 3/8 X 3” BUTTON HEAD BOLT 6988801 CABLE 3108406 3/8 X 3/4” FLAT HEAD BOLT 6714901 GUIDE ROD BUSHING 3102807 3/8” LOW HEIGHT LOCK NUT 6925801 LABEL, KEEP CLEAR 3221501 3/8”...
- Page 3 SECTION A-A 2"...
- Page 4 3/8 X 2-3/4” 14 3/8 X 3-3/4” 16 FIGURE 1 STEP 1: • LOOSELY assemble the top of the ARM SUPPORT (2) to the TOWER (1) using four RH CAPS (44), two 3/8 X 2-3/4” BOLTS (14), four 3/8” SAE WASHERS (21), four 3/8” RH WASHERS (23) and two 3/8” LOW HEIGHT LOCK NUTS (19) as shown in FIGURE 1.
- Page 5 3/8 X 3-3/4” 16 FIGURE 2 STEP 2: • LOOSELY assemble the SEAT FRAME (9) to the ARM SUPPORT (2) using four RH CAPS (44), two 3/8 X 3-3/4” BOLTS (16), four 3/8” SAE WASHERS (21), four 3/8” RH WASHERS (23), and two 3/8” LOW HEIGHT LOCK NUTS (19) as shown in FIGURE 2.
- Page 6 3/8 X 2-3/4” 14 FIGURE 3 STEP 3 • LOOSELY assemble the CROSS SUPPORT (8) to the ARM SUPPORT (2) and SEAT FRAME (9) using eight RH CAPS (44), four 3/8 X 2-3/4 BOLTS (14), eight 3/8” SAE WASHERS (21), eight 3/8” RH WASHERS (23) and four 3/8” LOW HEIGHT LOCK NUTS (19) as shown in FIGURE 3.
- Page 7 17 3/8 X 3” BUTTON HEAD FIGURE 4 STEP 4 • Slide two ACCORDION SLEEVES (33) and two PILLOW BLOCKS (26) over the PIVOT ARM (4) as shown in FIGURE 4 • Assemble four 3/8 X 3” BUTTON HEAD CAP SCREWS (17) and four STARLOCK WASHERS (43) to the the PILLOW BLOCKS (26) as shown in FIGURE 4.
- Page 8 13 3/8 X 2-1/2” FIGURE 6 STEP 6: • SECURELY assemble the COUNTERBALANCE (7) to the PIVOT ARM (4) using two RH CAPS (44), one 3/8 X 2-1/2” BOLT (13), two 3/8” SAE WASHERS (21), two 3/8” RH WASHERS (23) and one 3/8” LOW HEIGHT LOCK NUT (19) as shown in FIGURE 6.
- Page 9 FIGURE 8 STEP 8: • Insert two 1/2” FLANGE BEARINGS (25) into the HANDLE (3) as shown in FIGURE 8. • Attach one 1-1/4” RUBBER BUMPER (31) to the HANDLE (3) as shown in FIGURE 8 FIGURE 9 24 1/2 X 3-1/4” STEP 9: •...
- Page 10 3/8 X 3-1/2” 15 FIGURE 10 STEP 10 • SECURELY assemble the CAM SHROUD (6) to the ARM SUPPORT (2) using two RH CAPS (44), two BLACK RH CAPS (29), two 3/8 X 3-1/2” BOLTS (15), four 3/8” RH WASHERS (23) and two 3/8” LOW HEIGHT LOCK NUTS (19) as shown in FIGURE 10.
- Page 11 11 3/8 X 1-1/4” FIGURE 12 STEP 12: • SECURELY assemble the CHEST/ARM PAD (40) to the SEAT ADJUST (9A) using two RH CAPS (29), two 3/8 X 1-1/4” BOLTS (11) and two 3/8” RH WASHERS (23) as shown in FIGURE 12. (Note the the direction of the hole pattern on pad.) FIGURE 13 11 3/8 X 1-1/4”...
- Page 12 3/8 X 3/4” 18 FLAT HEAD FIGURE 14 STEP 14: • SECURELY assemble the 4 X 18” PLATE (10) to the SEAT FRAME (9) using two 3/8 X 3/4” FLAT HEAD BOLTS (18), two 3/8” RH WASHERS (23), two 3/8” LOW HEIGHT LOCK NUTS (19) and two 3/8” RH CAPS (44) as shown in FIGURE 14. FIGURE 15 11 3/8 X 1-1/4”...
- Page 13 FIGURE 16 HEAVY WEIGHT OPTION STEP 16: • Insert the two GUIDE RODS (37) (found in SHROUD KIT box) into the base of the TOWER (1) as shown in FIGURE 16. Lubricate the GUIDE RODS (37) with a slicon or teflon spray that is available at most hardware stores. •...
- Page 14 FIGURE 17 13 3/8 X 2-1/2” TIGHTEN! STEP 17: • SECURELY assemble the GUIDE ROD SUPPORT (5) to the TOWER (1) using four RH CAPS (44), two 3/8 X 2-1/2” BOLTS (13), four 3/8” RH WASHERS (23) and two 3/8” LOW HEIGHT LOCK NUTS (19) as shown in FIGURE 17. (NOTE: Be sure to route cable through the hole of the GUIDE ROD SUPPORT (5) before tightening.) •...
- Page 15 FIGURE 18 STEP 18: • The WEIGHT STACK LABEL sheet (42) includes labels for both lbs. and kgs. for both the standard and optional weight stacks. • Peel the backing off the WEIGHT STACK LABELS (42), line up sheet to the right of the selector opening and apply labels to the WEIGHT PLATES (38 or 39), starting with the HEAD PLATE (36) as shown in FIGURE 18.
- Page 16 FIGURE 19 STEP 19: • Assemble the PLACARD LABEL (34) or the FOREIGN LANGUAGE PLACARD LABEL (35) to the FRONT SHROUD as shown in FIGURE 19.
-
Page 17: Warranty Information
• Upholstery with mild soap and water. • Guide rods with a cotton cloth. • Hand grips with mild soap and water. • Frame damage can be repaired with touch-up paint purchased from your LifeFitness customer service representative at (800)328- 9714. Inspect: •...
