SOUTHERN ENTERPRISES INC.
NOTE.... This product has been engineered for
easy assembly and constructed for durability.
Please take time to read and follow assembly instructions.
No.
Description
A
Side Frame
B
Seat Frame
C
Slot
Assembly Instruction
PARTS AND HARDWARE LIST
Q'ty
Sketch
1
2
4
STYLE NO: BC922900TX-Espresso Black Seat Bench
No.
Description
1
Bolt(1/4"*1-1/2")
2
Washer
3
Wood Screw(8#*1-1/4")
4
Allen Wrench
Q'ty
Sketch
6
6
8
1
PAGE: 1 of 3
Advertisement
Table of Contents
Related Manuals for Southern Enterprises BC922900TX
Summary of Contents for Southern Enterprises BC922900TX
- Page 1 STYLE NO: BC922900TX-Espresso Black Seat Bench SOUTHERN ENTERPRISES INC. NOTE…. This product has been engineered for easy assembly and constructed for durability. Please take time to read and follow assembly instructions. Assembly Instruction PARTS AND HARDWARE LIST Description Q'ty Sketch...
- Page 2 STEP1: Connect the Side Frame (B) ＆ the Seat Frame (A) with 6pcs Washers (2) ＆ 6pcs Bolts (1) by using the Allen Wrench (4) as figure shown ! STEP2: Attach the Slot (C) with 8pcs Wood Screws (3) by using screwdriver (not included) as figure shown ! PAGE: 2 of 3...
- Page 3 If this product has not been purchased from our retail affiliates (within 9 months), we are under no obligation to provide parts or replacement merchandise. WE WILL SHIP PARTS IF AVAILABLE.THIS IS NOT A WARRANTY. PARTS REPLACEMENT FORM STYLE NO. : BC922900TX-Espresso Black Seat Bench Customer Name PARTS PART...
