- Page 1 Auto User's manual...
-
Page 2: Complete Set
BLAUBERG Company is happy to offer your attention a new generation product, the BLAUBERG Auto fan. The solid team of high-qualified professionals with many years of working experience, technological innovations in design and production, high-quality components and materials from the top worldwide producers have become the precondition for the best fan in its class. -
Page 3: Basic Characteristics
Humidity Timer Model Switch sensor sensor Auto ___ Auto ___ S Auto ___ T Auto ___ ST Auto ___ H Auto ___ SH Auto ___ IR Switch (S) - built-in pull cord switch; Timer (T) - turn-off time range from 2 to 30 min;... - Page 4 Fig. 1 1 - cover; 2 - casing; 3 - motor; 4 - impeller. Table 3 Dimensions [mm] Weight Model [kg] 0,56 Auto 100 Auto 125 0,73 Auto 150 Fig. 2...
-
Page 5: Operation Rules
OPERATION RULES The fan is rated for connection to 220...240 V / 50 Hz power mains and is designed for continuous operation always connected to power mains. The air motion direction in the system must match the pointer on the fan casing. The fan is rated for operation at ambient temperature from +1 °C up to +45 °C. - Page 6 The product is not allowed for use by children and persons with reduced physical, mental or sensory capacities, without proper practical experience or expertise, unless they are controlled or instructed on the product operation by the person(s) responsible for their safety. Supervise the children and do not let them play with the product.
-
Page 7: Mounting And Setup
MOUNTING AND SETUP The fan is designed for ceiling or wall mounting to extract air into a ventilation shaft or matching air duct of respective diameter (fig. 3-7). The fan mounting sequence is shown in fig. 8-9. The fan wiring diagr ams are shown in fig. - Page 8 Fig. 6 Fig. 7 Fig. 8 Fig. 9...
- Page 9 WIRING DIAGRAMS AND FAN OPERATING LOGIC Auto _____ Fig. 10 Fan does not run Switch is closed Fan runs Switch is opened S - external switch QF - automatic circuit breaker Auto _____S Fig. 11 Fan does not run Pull the cord switch...
- Page 10 Fig. 12 Auto _____T Fan does not run Switch is closed Fan runs Switch is opened Turn-off delay timer 2min starts (2 to 30 min) 30min S - external switch QF - automatic circuit breaker Fig. 13 Auto _____ST Fan does not run...
- Page 11 Fig. 14 Auto _____H 2min 30min S - external switch QF - automatic circuit breaker Fan does not run Switch is closed Humidity exceeds set point Fun runs Fun runs Switch is opened Humidity is below set point Humidity exceeds...
- Page 12 Fig. 15 Auto _____SH 2min 30min QF - automatic circuit breaker Fan does not run Pull the cord switch Humidity exceeds set point Fun runs Fin runs Pull the cord switch Humidity is below set point Humidity exceeds set point...
- Page 13 Fig.16 Auto _____IR Fan does not run Motion is detected Fun runs No motion detected 2min 30min Turn-off delay timer starts (2 to 30 min) QF - automatic circuit breaker Fig. 17 Warning! The timer circuit is under mains voltage! Disconnect the fan from power mains prior to any adjustment operations.
-
Page 14: Maintenance
MAINTENANCE Any servicing and maintenance operations of the fan are allowed after it is disconnected from power mains only. Maintenance means regular cleaning of the fan surfaces from dirt and dust. To clean the fan, wipe its surfaces with a cloth wetted in a mild soap solution, then wipe the surfaces dry. -
Page 15: Manufacturer's Warranty
MANUFACTURER'S WARRANTY The fan complies with the requirements according to the EU norms and directives, to the relevant EU-Low Voltage Equipment Directives, EU-Directives on Electromagnetic Compatibility. We hereby declare that the following product complies with the essential protection requirements of Electromagnetic Compatibility (EMC) Directive 2014/30/EU of the European Parliament and of the Council and Low Voltage Directive (LVD) 2014/35/EU of the European Parliament and of the Council and CE-marking Council... - Page 16 AUTO Model is recognized as serviceable. SALES DATE MANUFACTURED ON (DATE): SOLD APPROVAL MARK AUTO_EN-03...
