9. Turn the rotary knob, and select <Connection Type>, push the knob to confirm. G3 NET 2K support 8 kinds of
connection type, including
10. Turn the rotary knob, and select <Offset Settings>, push the knob to confirm, turn the rotary knob, and set
Port 1/2 Offset X and Port 1/2 Offset Y as 0, shown as follows:
11. Turn the rotary knob, and select <Position Settings>, push the knob to confirm, turn the rotary knob, and set
Port 1 X Position, Port 1 Y Position, Port 2 X Position as 0 and set Port 2 Y Position as 256, shown as follows:
The connection figure is shown as below:
